Mode Selection - Cameo PAR 64 CAN Manuel D'utilisation

mODE SELECTION:

STATIC COLOUR mODE
Press the "MODE" button to select the Static Colour Mode. "C000", then
press the "ENTER" button to choose one of the static colours using the
"UP" and "DOWN" buttons (2. digit blinks). The "C1" represents Red, "C2"
= Green, "C3" = Blue, "C4" = Amber and "CF" = strobe. Press ENTER
(3. and 4. digits blink) again to adjust brightness (C1, C2, C3, C4, 00-99)
or strobe speed ( CF, 00-99) by using UP and DOWN buttons. Examples:
If you set C1, C2, C3 and C4 to zero, the Tri Par will have no LEDs on
(blackout). If you set C1 to 99 and C2, C3 and C4 to zero, the Par will be
100% Red.
RED
00 - 99 beam brightness adjustable.
GREEN
00 - 99 beam brightness adjustable.
BLUE
00 - 99 beam brightness adjustable.
AmBER
00 - 99 beam brightness adjustable.
STROBE
00 - 99 speed adjustable.
