26. ON / OFF TRIGGER SWITCH
27. LASER GUIDE ON / OFF SWITCH
28. DUST EXTRACTION PORT
29. CABLE
30. CUTTING HEAD LOCKING PIN
31. REAR SLIDING CARRIAGE
32. CABLE GUIDE CLAMP
33. 33.9˚ BEVEL PIN
34. BEVEL LOCK HANDLE
35. M4 SELF TAPPING CAP SCREW x1
36. M4 SOCKET HEAD SCREW x4
33
37
38
37. CABLE GRIP COMPONENT
(FITTED TO THE CABLE GUIDE CLAMP)
38. ANTI-VIBRATION SPRING
(FITTED TO ITEM '4' - THE SLIDE LOCKING
SCREW)
