• This product is for use indoors.
• A mounting bracket is required.
• Since the monitor is heavy, consult your dealer before
installing, removing or moving the monitor.
• Mounting the monitor on the wall requires special expertise
and the work must be performed by an authorized SHARP
dealer. You should never attempt to perform any of this
work yourself. Our company will bear no responsibility
for accidents or injuries caused by improper mounting or
mishandling.
• Use the monitor with the surface perpendicular to a level
surface. If necessary, the monitor may be tilted up to 20
degrees upward or downward.
• This monitor should be used at an ambient temperature
between 32°F (0°C) and 104°F (40°C). Provide
enough space around the monitor to prevent heat from
accumulating inside.
For the monitor in landscape orientation
2
[5]
For the monitor in portrait orientation
7-7/8 [20]
2
[5]
2 [5]
• If it is difficult to provide sufficient space for any reason
such as the installation of the monitor inside a housing or
of several units side-by-side, or if the ambient temperature
may be outside of the range of 32°F (0°C) to 104°F (40°C),
install a fan or take other measures to keep the ambient
temperature within the required range. When installing two
or more monitor units side-by-side, provide space of at
least 3/16 inch (5 mm) around them to prevent stress on
the adjacent unit or structure due to thermal expansion.
• Temperature condition may change when using the monitor
together with the optional equipments recommended by
SHARP. In such cases, please check the temperature
condition specified by the optional equipments.
• Do not block any ventilation openings. If the temperature
inside the monitor rises, this could lead to a malfunction.
• Do not place the monitor on a device which generates heat.
4
E

MOUNTING PRECAUTIONS

Unit: inch [cm]
7-7/8 [20]
2 [5]
2
[5]
2 [5]
Unit: inch [cm]
2 [5]
2
[5]
Power LED
• Adhere to the following when installing the monitor in its
portrait orientation. Failing to adhere to the following may
cause malfunctions.
- Install the monitor such that the power LED is located on
the bottom side.
- Set the MONITOR on the MONITOR menu to PORTRAIT.
(See OPERATION MANUAL.)
• Use the supplied vertical sticker when you install the
monitor in portrait orientation.
Do not remove the factory-affixed sticker but affix the
sticker over it. Be careful not to cover the remote control
sensor or buttons.
• This monitor is fixed to the temporary stand used in the
package for transportation when shipped from the factory.
Please note that this stand is for temporary use only until
the monitor is properly mounted.
Logo
Operation panel
