FLAEM Neb-aid Mode D'emploi page 5

the doctor into the lower part (C1.1). Close the nebuliser by turning the upper part (C1.3)
clockwise.
3. Connect accessories as indicated in the "Connection
diagram" on the cover.
4. Sit comfortably holding the nebuliser in your hand, place
the mouthpiece onto your mouth or alternatively use the
nose piece or mask. Should you opt for the mask accessory,
place it on your face as shown in the picture (with or
without using the elasticated strap).
5. Turn on the device using the switch (A1) and then breathe
in and exhale deeply.
6. When the treatment is finished, shut off the device and unplug the power cord.
WARNING: If after the therapy session moisture accumulates in the tube (B), remove the
tube from the nebulizer and dry it using the device's compressor fan; this operation will
prevent mold from forming inside the tube.
HOW TO USE THE "RF7 DUAL SPEED" NEBULIZER WITH THE SPEED SELECTOR
Professional and fast, this device is suitable for administering all types of medications,
including more expensive ones,even in patients with chronic diseases. The geometry
of the internal lines of the RF7 Dual Speed nebulizer ensures the ideal granulometry for
active treatment all the way down to the lower respiratory tract.
To speed up the inhalation therapy, move the speed selector button
(C1.4) by pressing on MAX with your finger.
To increase the effectiveness of the inhalation therapy, press with your
finger on the wording MIN of the speed selector (C1.4). In this position,
the speed selector acts as a valve and allows nebulizing the optimal
amount of drug to the lower respiratory tract, reducing its dispersion in
the environment.
SOFTTOUCH FACE MASKS
Soft
biocompatible
material
Dispersion
Limiting Vent
During the inspiratory phase, the
tab, acting as a Dispersion Lim-
iting Device, bends inwards to-
wards the mask.
SoftTouch masks have an outer edge made of soft
biocompatible material that ensures excellent ad-
herence to the face, and is also equipped with an
innovative Dispersion Limiting Device. These dis-
tinctive elements that distinguish it allow greater
sedimentation of medication in the patient and also
limit dispersion.
During the expiratory phase, the
tab, acting as a Dispersion Limit-
ing Device, bends outwards from
the mask.
3
