Terminal
Signal type
^
−
X1/
24
X2/+O24
−
X2/VBr
−
Digital
X3/O5
outputs
X3/O6
X3/O7
X3/O8
X3/O9
X3/O10
Digital
X4/I9
inputs
X4/I10
X4/I11
X4/I12
X4/I13
X4/I14
(
Stop!
Ensure a sufficient dimensioning of the DC voltage supply, if the loads are
ƒ
connected to the digital outputs.
The extension board must exclusively be supplied separately.The internal
ƒ
supply via the Drive PLC is not permissible.
EDK10201EZ3 DE/EN/FR 5.1
Electrical installation
Assignment of the terminals
Function
GND, reference potential
DC supply voltage
DC supply voltage for
X3/O9, X3/O10
Technical data
18 VDC ... 30 VDC
18 VDC ... 30 VDC
LOW (0 V ... +4 V)
HIGH (+13 V ... +30 V)
Load capacity: max. 1 A
LOW (0 V ... +4 V)
HIGH (+13 V ... +30 V)
Load capacity: max. 2 A
LOW (0 V ... +4 V)
HIGH (+13 V ... +30 V)
Input current: max. 8
mA at 24 V
16
Remarks
Connected via
emergency off at the
Drive PLC
Always conduct via
emergency off
Suitable for brake
control
