A - Kit Contents; B - Description Of Monitor; C - Description Of The Intercom Panel - Extel Code 720309 Guide D'installation Et D'utilisation

A - KIT CONTENTS

Fig. 1
1
Monitor
2 Door plate
3 Surface mounting bracket
4
Monitor fixing bracket
5 Plug

B - DESCRIPTION OF MONITOR

Fig. 2
1 7" colour screen
2 Microphone
Screen off: Intercom panel preview
3 (surveillance mode)
Menu : left arrow or up arrow
During communication: Starts/ends
a call
Time screen: starts a call to the
4 second family screen (intercom)
In surveillance mode: initiates
communication
Menu: right arrow or down arrow
Screen off: Enables touch keys and
access to the time and then the menu
by pressing again
Screen off – button flashing:
5
access to photos of visitors when
absent
Menu: OK (selection button)
Call in progress: Takes a photo

C - DESCRIPTION OF THE INTERCOM PANEL

Fig. 3
1 Protective mirrored façade
2
Camera and infrared LEDs
3 Touchscreen code pad
4 Loudspeaker
Name holder (the transparent plastic can
5
be peeled back to write on the label)
6 Microphone
7 When on: button for calling family 1
EN2
Fixing screws for monitor bracket and
6
surface mounting bracket
Fixing screws for intercom panel in
7
mounting bracket
8 Modular power supply
In call or surveillance mode: Opens
6
electric strike plate
In call or surveillance mode: Opens
dry contact (gate motor drive)
7
Menu: Back/Exit (back button to
parent menu)
8 Loudspeaker
9 Power supply connectors
10 Slave or master button
Intercom panel and/or secondary
11
monitor communication connector
8 When on: call button
9 When on:button for calling family 2
Dawn-to-dusk cell capable of detecting
10
ambient brightness
Monitor, electric strike plate and gate
11 motor drive connectors (for details, see
Fig. 7)
Extel - Code - 720309-720311
