without it. We recommend sending it as a parcel, so that in
cases of loss an inquiry or proof of delivery is possible.
Battery notices:
The device associated with this operating manual contains two
AA Alkaline batteries (1.5 V) in delivery condition. These batter-
ies are not made for recharging. The use of rechargeable
batteries is not possible with this device and can damage it.
If the included batteries are depleted, they must not be thrown
into the household waste. Used batteries may contain harmful
substances that can cause environmental or health damage.
Please return all depleted batteries to electrical appliance
stores.
Battery exchange:
To replace the batteries, push the battery cover on the back
of the unit downwards and replace the discharged batteries
with two new ones. Be aware of the polarity when inserting the
batteries (+/- pole). Put the battery compartment cover on the
rear panel and press it gently on the device until it clicks.
All depleted batteries can be recycled. This way valuable
resources like iron, zinc and nickel can be retrieved and are
reusable then. Battery recycling is the easiest lesson in
environmental protection - please support it!
The shown garbage bins mean that batteries must not be thrown
into the household waste. The signs below the garbage bins
are acronyms for the chemical substances inside the battery:
Hg: Battery
contains Mercury
Cd: Battery
contains Cadmium
Pb: Battery
contains Lead
Technical data*:
Sensor
Accuracy
Detection Range
Warm-up Time
Dimension
Weight
Power Supply
Working Temperature
Storage Temperature
Calibration
*The technical data are subject to change without
prior notice for functional improvements.
Semiconductor sensor
+/- 0.10‰ (per mill) with reference
to 0.50‰ (per mill = default setting
in the EU)
OR +/- 0.01% with reference to 0.05%
BAC (default setting in the USA)
OR +/- 0.05mg/L with reference to
0.25mg/L (default setting in UK)
0.000 - 4.000‰ (per mill)
OR 0.000 - 0.400% BAC (USA)
OR 0.000 - 2.000mg/L (UK)
Within < 1 minute at 0.5‰
(‰ = EU setting), the warm-up time
may vary depending on the value
of per mill which was measured in
a test shortly done before
105 x 50 x 18 mm (H x W x T)
98g (batteries included)
2 pieces of 1.5V AA size Alkaline
battery
10°C - 40°C
0°C - 50°C
After 300 tests or approx. every
6 months (depending which
incident happens first)
For a calibration service you can
send the device to ACE Instruments
(see www.ace-instruments.net).
