Functions:

Calibration (Press Cal Key for 3 Seconds):
•
CAL
Select the calibration routine pH or Redox by Up or Down key.
o
ENT
Standard Routine calibration pH probe is 7 and 4 buffer solution and Redox 465 mV buffer
o
solution
Set Point (Press Mode Key):
•
Press Mode Key and choose SetPoint and adjust value with Up or Down Key before press
o
ESC
Enter and confirm.
MODE
prog
Press Cal and Mode Key (both) for 5 Seconds and run Program Setup:
•
Program Menu (Press Enter to Mode the following Item)
o
CAL
ENT
ESC
MODE
Save and escape Program setup with ESC key
•
Exit
o
Priming Pump Keep Press UP Key for 1 seconds and priming redox pump
•
priming 700mv
o
Priming Pump Keep Press Down Key for 1 seconds and priming pH pump
•
priming 7.2ph
o
Lock pump function
•
Press Up and Enter (both) after 5 second flash Rx Stop press again to unlock
o
Press Down and Esc (both) after 5 second flash pH Stop press again to unlock
o
The unit doses in proportional mode respect at Set Point (minimum distance 25%, maximum
•
distance 90% of 10 minutes time period dosing)
Note: The unit in program menu to go out in automatic mode after 1 minutes of wait time, the unit
doesn't save nothing.
0000137934
Instruction Setting
§ Sp 750mv 700 mv
§ Sp 7.4ph 7.6 ph
§ Language_ (It's possible to have 5 language EN, IT, SP, DE, FR)
§ Redox Measure
Setpoint 750 mv (Adjust value with enter and up or down key) It's possible
•
to adjust from 0 to 1000 mV value for Redox
Sp type low (Adjust value LOW or HIGH)
•
Ofa time 000 min (Adjust value OFF or set Time)
•
Alarm band 000 rx (Adjust value from 100 to 300 mV )
•
Type PROP (Adjust value between OFF, PROP, ON/OFF or TIMED)
•
(only if set to Timed there are two new entries to make a dosage cycles ON
/ OFF selectable)
§ Timed ON (Change the value from 1 to 120 minutes)
§ Timed OFF (Change the value from 1 to 120 minutes)
§ ph Measure
Setpoint 7.4ph (Adjust value with enter and up or down key) It's possible to
•
adjust from 0 to 14 pH value.
Sp type acid (Adjust value ACID or ALKA)
•
Ofa time 000 min (Adjust value OFF or set Time)
•
Alr band 000 ph (Adjust value from 1 pH to 3 pH)
•
Temp 25*C(Adjust value with enter and up or down key) pH measure only.
•
Type PROP (Adjust value between OFF, PROP or ON/OFF )
•
§ Flow (Adjust value with enter and up or down key Enable or Disable)
It's possible to enable(ON) or disable (OFF) signal input
•
§ Calibration probe (Adjust value with enter and up or down key)
Full (pH 7 and 4, Redox 465 mV buffer solution)
•
Easy (pH 7, Redox 465 mV buffer solution)
•
Off (Disabled)
•
§ Password (Adjust value with enter and up or down key, standard value 0000)
save (Adjust value with up or down key and confirm with enter key)
rev. 1.0
