EINHELL OPAL Instructions De Montage page 9

Page 35
9
Assembly of the wind bracing and struts
Top parts list: Front wall with single door
Bottom parts list: Front wall with double door
Note: Make sure that the struts are installed
horizontally. If necessary, use a spirit level to check.
Page 36
Fig. 9/c: Front wall with single door
Page 37
Fig. 9/c: Front wall with double door
9/d: Install the two bottom struts so that the angled
wind bracing fits in front of the one strut and behind
the other (see reference diagram on the next page).
Page 38
Reference diagram (Fig. – Front wall with
single door)
Note: Make sure that the struts are installed
horizontally. If necessary, use a spirit level to check.
Carefully tighten the bolts on the wind bracing and
the struts. This provides the necessary stability for
the front wall.
Page 39
Installation of the rear wall assembly
Repeat steps 1 to 6.
Please note: In step 1 „Pre-assembly of the floor
profile", use the floor gusset plate (art. no.
84.620.21) in place of the mounting bracket, short
(art. no. 84.631.51) Working from the outside,
attach the gusset plate to the floor profile at the two
upper holes using two hexagon bolts and nuts.
After step 6 in the assembly go straight to step 10.
10
Assembly of the struts (rear wall)
Page 40
10/c: Make sure that the strut with the three pre-
assembled bolts is inserted in the middle.
Page 42
Reference diagram (internal view)
Note: The cutouts on the floor profile and the
crossmember marked with an X in the reference
diagram stay free. Make sure that the strut with just
three pre-assembled bolts is inserted in the middle!
Check the distances between the bolts.
ABA_OSR_Teil1_Titel+GB.pmd 9
Page 43
11
Installation of the wind bracing and struts
on the rear wall
Note: Make sure that the struts are installed
horizontally. If necessary, use a spirit level to check.
Page 45
11/d + 11/e: Install the two bottom struts (DT)
(602 mm) in such a way that the angled wind bracing
fits in front of the one strut and behind the other (see
Fig. 11/e).
Page 46
Note: Make sure that the struts are installed
horizontally. If necessary, use a spirit level to check.
Carefully tighten the bolts on the wind bracing and
the struts. This provides the necessary stability for
the front wall.
Page 47
12
Pre-assembly of the side floor profile
Middle illustration: Assembly preview of a
greenhouse with 3 panels
Bottom illustration: Assembly preview of a
greenhouse with 4 panels
Page 48
Top illustration: Assembly preview of a greenhouse
with 5 panels
Middle illustration: Assembly preview of a
greenhouse with 6 panels
Bottom illustration: Assembly preview of a
greenhouse with 7 panels
Page 49
Important note: If you have purchased a 3-panel
greenhouse, skip steps 12/a and 12/b and continue
with assembly step 12/c.
Page 50
Important note: If you have purchased a steel base
(optional accessory) for your 3-panel greenhouse,
then you will need to install additional bolts on the
floor profile. If you are not using a steel base, please
skip step 12/c and continue with assembly step 12/d.
Fig. 12/c: Floor profile for a greenhouse with
3 panels
12/c: Slide three bolts into each floor profile guide rail
of the 3-panel greenhouse (slide the bolts to the
middle – see assembly preview). This will be needed
