Using the control box

7 Using the control box
7.1

Manual operation

You can operate the control box manually. With manual operation, you activate a certain
camera by hand via the switch supplied.
In manual operation you must also switch the monitor on manually if it is to display a
picture.
➤
Connect the cables of the switch (fig. 3 3, page 4) according to the assignment on
page 22.
➤ Place the switch in the desired position in order to switch on the corresponding
camera:
– B: reversing camera (CA1) (fig. 6 1, page 6)
– L: left camera (CA2) (fig. 6 2, page 6)
– R right camera (CA3) (fig. 6 3, page 6)
Note
I
There is no signal on the control cable of the monitor during manual operation
when the switch is connected.
7.2

Automatic operation

You can operate the control box in automatic mode. In the automatic mode the cameras
switch on or off automatically according to the control signal present. The monitor is
activated automatically via the control box.
Note
I
During automatic operation a signal of +12 V is present on the control cable of
the monitor when one of the indicators or the reverse gear is activated.
The camera whose control cable is active is always activated in automatic mode
(priority to reverse gear). If the situation arises, a switch position deviating from
this is ignored.
➤
Connect the green line of the vehicle electrics connection cable to the right indicator
light.
➤
Connect the brown line of the vehicle electrics connection cable to the left indicator
light.
➤
Connect the orange line of the vehicle electrics connection cable to the reversing
light.
