Battery Specifications - Hach RTC Standardized Combined CX5130 Manuel D'installation

Battery specifications

Explosion hazard. Incorrect battery installation can cause the release of explosive gases. Be sure that
the battery is of the approved chemical type and is inserted in the correct orientation.
Note: Replace the battery each five years.
The correct battery specifications are:
Specification
Battery type
Nominal voltage at 20 °C
Nominal capacity at 20 °C
Standard conditions (continuous load)
Dimensions (Diameter x Height)
Weight
CP27xx—Replace the battery or CFast card
Electrocution hazard. Remove power from the instrument before doing maintenance or service
activities.
Explosion hazard. Incorrect battery installation can cause the release of explosive gases. Be sure that
the battery is of the approved chemical type and is inserted in the correct orientation.
Note: Make sure that the battery is in the correct polarity and is the correct type.
To replace the battery or the CFast card, refer to the illustrated steps that follow.
14 English
C A U T I O N
D A N G E R
C A U T I O N
Details
CR2032
3.0 V
0.20 mA
0.20 mA
20.0 x 3.20 mm
3.1 g
