sigfox DRY CONTACTS- Guide utilisateur / User guide version V1.2.0
4.1.3 Network configuration data frames
Following reception of a downlink frame with the code 0x02 or on switching to the operating mode (from the Park or Command Mode), the
next frame (0x20) representing the network configuration of the product is transmitted:
0
1
Code
Status
0x20
Cf status
0x20
0xA3
0x02
Description of the frame:
• Byte 2 : register 302, nomber of repetition
In the example in grey this gives:
• Byte 2=0x02: the nomber of repetition will be 2
This frame (0x30) is only issued when the different digital outputs are configured in the event mode or in output and at the frequency defined
by register 300.
0
1
Code
Status
0x30
Cf Status
0x30
0xAB
As the example shows it only contains the value of the status byte.
4.1.4 Data Frame
This frame (0x42) contains the values measured on the different digital outputs.
0
1
Code
Status
0x40
Cf Status
Informations TOR1
0x40
0xAB
Description of the frame:
•
Byte 2 and 3: Information on the TOR1
•
If configured as an input (event or Periodic mode): these bytes contain the value of the event counter of Input TOR1
•
If configured as an output: current state of the output TOR1
•
Byte 4 and 5: Information on TOR2
•
If configured as an input (event or Periodic mode): these bytes contain the value of the event counter of Input TOR2
•
If configured as an output: current state of the output TOR2
•
Byte 6 and 7: Information on TOR3
•
If configured as an input (event or Periodic mode): these bytes contain the value of the event counter of Input TOR3
•
If configured as an output: current state of the output TOR3
2
3
4
202
X
X
2
3
4
X
X
X
2
3
4
Informations TOR2
0x00F1
0x0002
5
6
7
PAYLOAD
X
X
X
5
6
7
PAYLOAD
X
X
X
5
6
7
PAYLOAD
Informations TOR3
0x0001
8
9
10
X
X
X
8
9
10
X
8
9
10
Informations TOR4
Détails
0x0000
0x9C
Page
65
of 80
