sigfox DRY CONTACTS- Guide utilisateur / User guide version V1.2.0

1. PRODUIT PRESENTATION

IMPORTANT NOTE: The sigfox DRY CONTACTS can only be started with a magnet.
Description:
• The ADEUNIS RF sigfox DRY CONTACTS is a ready-to-use radio transmitter enabling the user on one hand to transfer statuses and alarms on a
sigfox network and on the other to control relays via the same network.
• This product meets the needs of users who require to remotely monitor (or control) simple on-off digital data: detection of door opening,
presence, machine starting, warning, etc.
• The use of the sigfox protocol allows you to integrate the sigfox DRY CONTACTS into any network that is already deployed.
• Four digital inputs/outputs can be supported by a single sigfox DRY CONTACTS transmitter.
• The product emits the data either periodically or in an event-related way on a change of state.
• The configuration of the transmitter is accessible by the user via a micro-USB port, allowing in particular a choice of modes of transmission,
periodicity or type of interface (input/output).
• The sigfox DRY CONTACTS is powered by a replaceable internal battery.
IMPORTANT NOTE: The sigfox DRY CONTACTS is delivered by default with OTAA configuration, allowing the user to declare his/her product to a
sigfox operator. For an ABP procedure, please contact our Sales Department with the necessary information.
Composition of the package
The product is supplied in a cardboard box containing the following items:
top casing, electronic card, casing base plate,
cable gland, 3 gland seals, 2 CBLZ 2.2 x 19mm screws, 2 Fischer SX4 plugs,

1.1. General description

Casing base
Antenna
2 holes for passing
collars through
4 fastening holes
Rail-DIN unlocking
lever
Casing base detail
Cables outlet
packing gland
