Then selecting menu option „DiseqC Monitor" in the control panel of the SamYSo-
lar+® system.
The display now shows the DiseqC satellite number that receiver sent when chan-
ging the channel.
E
Information displayed at the SamYSolar+® control panel:
e.g. or e.g.
Sat number: 1 Sat number: 2
Satellite position „1" Satellite position „2"
After having selected a channel at the receiver, the position number of the satellite
assigned to this channel in the receiver must be displayed. This is essential for the
correct function of the system. If this is not the case, do not continue the confi -
guration process, as the DiseqC function will defi nitely not work.
In our example, the fi gure 1 should be displayed when an Astra channel is
selected, as Astra has been assigned to position A (1). When switching to a
Hotbird channel, the fi gure 2 should be displayed, as this satellite has been
assigned to position B (2).
If the position display functions correctly, the satellite position is assigned to the
corresponding satellite in the SamYSolar+® control panel. To do this, select the
menu option „SAT position".
In our example, we now assign position 1 to the Astra 1 satellite, and position
2 to the Eutelsat-Hotbird satellite.
