Installation

Transport

3
1 Hoisting belt (4x)
2 Wooden retaining beam (2x)
3 Hoisting belt position (4x)
Component
Burner
st
1 Heat exchanger
nd
2 Heat exchanger
rd
3 Heat exchanger
(only R3600SB series)
Frame
H for R3600SB in ( )
Condensate receptacle
18
R3401
R3600SB
m [kg] 135 135
L [mm] 1010 1010
W [mm] 1150 1150
H [mm] 420 420
m [kg] 120 120
L [mm] 1010 1030
W [mm] 1150 1150
H [mm] 160 150
m [kg] 135 135
L [mm] 1010 1030
W [mm] 1150 1050
H [mm] 160 150
m [kg] - 135
L [mm] - 1030
W [mm] - 1050
H [mm] - 150
m [kg] 50
L [mm] 1325 1325
W [mm] 1165 1165
H [mm] 460 360
m [kg] < 25 < 25
L [mm] 1320 1320
W [mm] 990 990
H [mm] 400 275
1
2
R3402 R3403
R3501 R3502
R3601SB R3602SB
140 210
1010 1420
1310 1010
500 500
135 180
1010 1420
1310 1010
160 160
150 200
1010 1420
1310 1010
160 160
150 200
1010 1420
1310 1010
160 160
50 60 70
1630 2004
1266 1066
500 (370) 500 (370)
< 25 < 35
1450 1950
1070 770
400 400
Boiler transport
The R3400/R3500/R3600SB boiler will
be supplied as a complete unit being
fully assembled and pre-tested. The
boiler can be transported with a pallet
truck (at least 1m wide), picking the
boiler up from the side.
Whenever necessary, the boiler can be
dismantled into smaller parts for easier
transport inside the building. The table
below shows the main dismantled parts
with their weight and dimensions.
When the R3400/R3500/R3600SB boi-
ler has to be transported with a crane, it
is necessary to remove the casing be-
fore connecting the boiler to the crane.
Always connect the crane to the frame
of the boiler by using straps.
R3404 R3405
R3503 R3504
R3603SB R3604SB
215 220
1420 1420
1110 1210
500 500
185 190
1420 1420
1110 1210
160 160
200 210
1420 1420
1110 1210
160 160
200 210
1420 1420
1110 1210
160 160
70 70
2004 2004
1066 1266
500 (370) 500 (370)
< 35 < 35
1950 1950
870 970
400 400
R3406
R3505
R3605SB
225
1420
1310
500
195
1420
1310
160
210
1420
1310
160
210
1420
1310
160
70
2004
1266
500 (370)
< 35
1950
1070
400
