2
Install the filters
1
Place the True HEPA Filter
within the Filter Frame.
Please make sure that the True
HEPA Filter is placed in proper
orientation.
Do not install the filter backwards or
the unit will not operate properly.
2
Place the Active Carbon Filter on
top of the True HEPA Filter with
the bands (2 places) facing up.
Place the Pre-filter through
3
the bands (2 places) lo-
cated in the corners of the
Active Carbon Filter.
Insert the tabs of the pre-filter into
the associated holes of the Filter
Frame.
4 Mount the Filter Frame to
the main unit.
Fix the Front Panel to the
5
main unit.
Fill in the usage start date
6
on the Date Label.
Use the date as a guide for the
Filter Replacement schedule.
Filter Frame
Band
Active Carbon Filter
True HEPA Filter
Filter Frame
Holes
Main unit
Filter Frame
Band
Date Label
E-11
True HEPA Filter
Tabs (4 places)
Band
