Xerox Phaser 7300DN Guide D'installation Et De Référence

Masquer les pouces

page de 44

/ 44
Signets

Liens rapides

Télécharger ce manuel

All manuals and user guides at all-guides.com

7300

P h a s e r

C o l o r P r i n t e r

Setup

and

Reference

Petit guide d'installation et de référence

Quick

Installazione e guida rapida

Setup und Kurzübersicht

Guide

Guía de configuración y referencia rápida

Guia de configuração e referência rápida

Installatie- en Referentiehandleiding

Installations- och snabbreferensguide

Installasjonsveiledning og hurtigreferanse

Installations- og Referencevejledning

Asetus- ja pikaohje

Sommaire des Matières pour Xerox Phaser 7300DN

Page 1 All manuals and user guides at all-guides.com 7300 P h a s e r ® C o l o r P r i n t e r Setup Reference Petit guide d'installation et de référence Quick Installazione e guida rapida Setup und Kurzübersicht Guide Guía de configuración y referencia rápida...
Page 2 All manuals and user guides at all-guides.com Installation Watch the Setup Video Installation Installazione Regarder la vidéo de configuration Visione del video di impostazione Instalación Setup-Video ansehen Instalação Vea el vídeo de instalación 7300 ® P h a s e r Assista ao vídeo de Configuração C o l o r P r i n t e r Bekijk de installatievideo...
Page 3 All manuals and user guides at all-guides.com Unpacking Déballage Disimballaggio 68 kg Auspacken 149 lbs. Desembalaje Desembalagem Uitpakken Packa upp Utpakking Udpakning Purkaminen pakkauksesta 70 cm (28 in.) *7300LTD *7300LTA 42 cm (16.5 in.) Option 20 cm 42 cm (8 in.) Option Alternativ Opcje...
Page 4 All manuals and user guides at all-guides.com Prepare Toner Remove Tape Retirez la bande adhésive Préparation du toner Rimuovere il nastro Preparare il toner Toner vorbereiten Klebeband entfernen Preparación del tóner Extracción de la cinta Remoção da Fita Preparar toner Verwijder tape Bereid de toner voor Ta bort tejp...
Page 5 All manuals and user guides at all-guides.com 0:10:00 Limit Light Exposure Limiter l’exposition à la lumière Begränsa ljusexponering Limite esposizione alla luce Nur kurz dem Licht aussetzen Begrens lyseksponeringen Limite la exposición a la luz Begræns udsættelse for lys Limite de exposição à luz Varo altistamasta valolle Beperk blootstelling aan licht Remove Packing Material...
Page 6 All manuals and user guides at all-guides.com Install Toner Cartridges Installez les cartouches de toner Installare le cartucce di toner Tonerkartusche installieren Instale los cartuchos de tóner Instale os cartuchos de toner Installeer de tonercassettes Installera tonerkassett Installer tonerkassetter Installation af tonerpatroner Asenna väripatruunat Shake Skaka...
Page 7 All manuals and user guides at all-guides.com Startup toner usage: see page 40 Utilisation du toner de démarrage : voir page 40 Toneranvändning vid start, se sidan 40 Avvio utilizzo toner: vedere pag. 40 Erster Tonereinsatz: siehe Seite 40 Bruk av oppstartstoner: se side 40 Uso de tóner en el arranque: consulte la página 40 For tonerforbrug ved start, se side 40 Uso de toner inicialização: consulte a página 40...
Page 8 All manuals and user guides at all-guides.com Connect Cables Connect Power Phaser 7300 Connectez les câbles Branchement Ready To Print Collegare i cavi Accendere Netzkabel anschließen An Netz anschließen Conexión de los cables Conexión de la alimentación Conexão de Cabos Conectar alimentação Verbind de kabels Schakel de stroom in...
Page 9 All manuals and user guides at all-guides.com Default language Select Language Install Drivers is English. PHASER 7300 READY TO PRINT Menus Printable Pages Sélectionnez la langue Printer Identification Installer les pilotes Support Selezionare la lingua Installa driver PHASER 7300 READY TO PRINT Sprache auswählen Treiber installieren Menus...
Page 10 All manuals and user guides at all-guides.com To avoid severe electrical Caution F= 50°-90° 10%-85% shock, use proper ground. C= 10°-32° Attention Pour éviter les risques d'électrocution, utilisez une mise à la terre appropriée. Attenzione Per evitare gravi scosse elettriche, usare la massa adatta.
Page 11 All manuals and user guides at all-guides.com Avoid hot surfaces. While printing... Eviter les surfaces brûlantes. Pendant l'impression… Evitare le superfici calde. Stampa in corso… Berühren Sie keine heißen Während des Druckvorgangs... Oberflächen. Mientras está imprimiendo... Evite las superficies calientes. Enquanto estiver imprimindo...
Page 12 All manuals and user guides at all-guides.com Printing Documentation Impression de la documentation Documentazione di stampa Druckerdokumentation Impresión de documentación Impressão de documentação Documentatie voor afdrukken 7300 ® P h a s e r C o l o r P r i n t e r Utskriftsdokumentation Interactive Documentation...
Page 13 (refer to page 16) (voir page 16) (vedere pag. 16) (siehe Seite 16) • web site: • Site Web : • sito Web: • Website: www.xerox.com/officeprinting/support www.xerox.com/officeprinting/support www.xerox.com/officeprinting/support www.xerox.com/officeprinting/support Las Guías de referencia: Guias de referência: Referensguider: Naslaghandleiding: Guía de instalación Guia de Configuração...
Page 14 All manuals and user guides at all-guides.com Front Panel Controls Cancel Commandes du panneau avant Avbryt Annuler Annulla Controlli del pannello frontale Abbrechen Avbryt Elemente des vorderen Bedienfelds Cancelar Annullér Peruuta Controles del panel frontal Cancelar Annuleren Controles do painel dianteiro Besturingselementen van het voorpaneel Frontpanelens kontroller Frontpanelkontroller...
Page 15 All manuals and user guides at all-guides.com Up Arrow Flèche haut Upp-pil Freccia su Nach oben Pil opp Flecha arriba Op-pil Seta para cima Ylänuoli Pijl-omhoog P h a s e r 7 3 0 0 Information Information key — (press at any time) De toets Informatie —...
Page 16 All manuals and user guides at all-guides.com Printable Pages P h a s e r 7 3 0 0 Pages imprimables Pagine di stampa Druckbare Seiten Printable Pages Menu Páginas imprimibles Help pages can be printed from the front panel on a Pages imprimables Menu variety of subjects: Menu Map, Help Guide, Paper Tips, Menu Pagine di stampa...
Page 17 All manuals and user guides at all-guides.com Print Configuration Pages Print Supplies Page Print Help Guide Imprimer la page de configuration Imprimer le Guide d'assistance Imprimer la page des consommables Stampa pagina di configurazione Stampa pagina materiali di consumo Stampa guida Konfigurationsseite drucken Hilfeanleitung drucken Verbrauchsmaterialseite drucken...
Page 18 Hilfsprogramme management software, access the web site: • accéder directement aux mises à jour et all'assistenza tecnica. www.xerox.com/officeprinting/7300support au support technique. Administración de la and click the CentreWare link. Per maggiori informazioni sul software di Pour plus d'informations sur ce logiciel,...
Page 19 Para obtener más información sobre el software de gerenciamento de impressora, auf der Website software de administración de la impresora, acesse o site da web: www.xerox.com/officeprinting/7300support vaya al sitio web: www.xerox.com/officeprinting/7300support Wählen Sie dort den Link zu CentreWare. www.xerox.com/officeprinting/7300support e clique no link do CentreWare.
Page 20 All manuals and user guides at all-guides.com Loading Paper Chargement du papier Caricamento della carta in corso Einlegen von Papier Printable Pages Menu Carga de papel Pages imprimables Menu Menu Pagine di stampa Colocação de papel Menü Druckbare Seiten Menú Páginas imprimibles Papier plaatsen Menu Páginas Imprimíveis Ladda papper...
Page 21 All manuals and user guides at all-guides.com 64 g/m – 203 g/m (17 lb. bond – 75 lb. cover/112 lb. index) 64 g/m – 163 g/m Statement..5.5 x 8.5 in. (17 lb. bond – 60 lb. cover/90 lb. index) Executive..
Page 22 All manuals and user guides at all-guides.com Changing Paper Type Changement du type de papier Modifica tipo di carta Ändern der Papiersorte Modificación del tipo de papel Alteração do tipo de papel Papiertype wijzigen Ändra papperstyp Endre papirtype Udskiftning af papirtype Paperityypin vaihtaminen Set Paper Type Plain Paper...
Page 23 All manuals and user guides at all-guides.com If you change the type of paper or Si vous changez le type de papier ou de Se viene modificato il tipo di carta o di Wenn Sie die Papiersorte oder die Si cambia el tipo de papel o Phaser 35-Series transparencies, you transparents Phaser série 35, vous lucidi Phaser Serie 35, è...
Page 24 All manuals and user guides at all-guides.com Multi-Purpose Tray* 18 in.- 36 in. 457 mm - 914 mm Bac multisupport Cassetto multiuso Mehrzweckfach Bandeja multiuso Bandeja de multiformatos Multifunctionele lade Flerfunktionsfack Flerfunksjonsskuff Multibakke Monikäyttölokero Legal Letter Tabloid ISO B5 Tabloid Extra B5 JIS Executive Statement...
Page 25 All manuals and user guides at all-guides.com Manual 2-Sided Printing Impression recto-verso manuelle Stampa fronte retro manuale Manueller Duplexdruck Impresión manual a dos caras Impressão manual em frente e verso Handmatig dubbelzijdig afdrukken Manuell dubbelsidig utskrift Manuell tosidig utskrift Manuel dobbeltsidet udskrivning 2-puolinen tulostus käsinsyötöllä...
Page 26 All manuals and user guides at all-guides.com Automatic 2-Sided Printing ® Phaser 7300-DX/MDX ® Phaser 7300-DT/MDT Impression recto-verso automatique ® Phaser 7300-N/MN Paper types: Plain Paper, ® Phaser 7300-B/MB Letterhead, or Special only Stampa fronte retro automatica 75 –105 g/m Types de papier : ordinaire, à...
Page 27 Use only Xerox Phaser 35-Series transparencies Transparents Utiliser exclusivement les transparents Phaser Lucidi série 35 Xerox Usare solo lucidi Xerox Phaser serie 35 Transparentfolien Nur Transparentfolienfilm der Serie Xerox Phaser 35 verwenden Transparencias Utilice sólo la película de transparencia Xerox Transparências...
Page 28 All manuals and user guides at all-guides.com Envelopes Enveloppes Buste Umschläge Sobres Envelopes Enveloppen Kuvert ≤ 105 gm (28 lb. bond) Konvolutter Konvolutter Kirjekuoret #10 (4.12 x 9.5 in.) C4 (229 x 324 mm) Monarch (3.87 x 7.5 in.) A7 (5.25 x 7.25 in.) DL (110 x 220 mm) C5 (162 x 229 mm) C6 (114 x 162 mm)
Page 29 All manuals and user guides at all-guides.com Labels Etiquettes Etichette Aufkleber Etiquetas Etiquetas Labels Etiketter Etiketter Etiketter Tarrat Letter 1-50 Also see infoSMART www.colorconnection.xerox.com on Page 41. for templates, tips, and tutorials...
Page 30 Cartões e inserções de CD/DVD Kaarten en CD/DVD-mapjes Kort och CD/DVD-inlägg Kort og CD/DVD-innlegg Kort- og CD/DVD-indsætninger Kortit ja CD/DVD-levyjen kannet A/Letter 8.5 x 11 in. 210 x 297 mm 1-25 Also see infoSMART www.colorconnection.xerox.com on Page 41. for templates, tips, and tutorials...
Page 31 All manuals and user guides at all-guides.com Manual 2-sided printing Impression recto-verso manuelle Stampa fronte retro manuale Manueller Duplexdruck Impresión manual a dos caras Impressão manual em frente e verso Handmatig dubbelzijdig afdrukken Manuell dubbelsidig utskrift Reseal bag to retain humidity Manuell tosidig utskrift Refermez le sac pour éviter tout dessèchement Manuel dobbeltsidet udskrivning...
Page 32 All manuals and user guides at all-guides.com Paper P h a s e r 7 3 0 0 Jams Bourrages papier Inceppamenti della carta 0:10:00 Papierstaus Top Cover Atascos de papel Capot supérieur Limit Light Exposure Atolamentos de papel Coperchio superiore Limiter l’exposition à...
Page 33 All manuals and user guides at all-guides.com...
Page 34 All manuals and user guides at all-guides.com Door A Capot A Sportello A Tray 1-5 Abdeckung A Bac 1-5 Puerta A Cassetto 1-5 Porta A Fach 1-5 Klep A Bandeja 1-5 Lucka A Bandeja 1-5 Lade 1-5 Fack 1-5...
Page 35 All manuals and user guides at all-guides.com Duplex Unit Unité recto-verso Unità duplex Duplexeinheit Unidad de impresión a dos caras Unidade frente e verso 0:10:00 Eenheid voor dubbelzijdig afdrukken Duplexenhet...
Page 36 All manuals and user guides at all-guides.com Print-Quality Problems Problèmes de qualité d'impression Support Menu Menu Support Problemi di qualità di stampa Menu Supporto Menü Support Probleme mit der Druckqualität Menú Asistencia Menu Suporte Problemas de calidad de impresión Problemas de qualidade de impressão Problemen met de afdrukkwaliteit Improve Print Quality? Améliorer la qualité...
Page 37 All manuals and user guides at all-guides.com Color Calibration Etalonnage couleur Calibrazione del colore Support Menu Farbkalibrierung Menu Support Menu Supporto Calibración del color Menü Support Menú Asistencia Ajuste de cor Menu Suporte Kleuren kalibreren Färgkalibrering Improve Print Quality? Améliorer la qualité d'impression ? Fargekalibrering Migliorare qualità...
Page 38 B/Tabloid 11 x 17 in. Phaser Premium farveudskrivningspapir 11 x 17 in. Suministros Xerox 016-1699-00 Phaser Premium -väritulostuspaperi 016-1718-00 Produtos de consumo da Xerox 297 x 420 mm 297 x 420 mm Xerox-toebehoren 016-1700-00 016-1719-00 Tabloid Extra Tabloid Extra Xerox-tillbehör 12 x 18 in.
Page 39 Premium visitkort med kuvert 8.5 x 11 in. Letter 016-1894-00 8.5 x 11 in. Phaser Premium visittkort Xerox standard transparenter for 35-serien Gratulasjonskort premium med konvolutter 016-1898-00 Phaser Premium Visitkort Phaser 35-Series standard-transparenter Premium postkort med konvolutter Phaser Premium -käyntikortit...
Page 40 All manuals and user guides at all-guides.com Standard-Capacity Toner Cartridge Imaging Unit * High-Capacity Toner Cartridge Cartouche de toner de capacité standard Cartouche de toner grande capacité Unité imageur Cartuccia di toner ad alta capacità Cartuccia di toner a capacità standard Unità...
Page 41 All manuals and user guides at all-guides.com 1650-Sheet High-Capacity Feeder 550-Sheet Feeder Duplex Unit Bac grande capacité de 1650 feuilles Bac de 550 feuilles Unité recto-verso Alimentatore alta capacità da 1650 fogli Alimentatore da 550 fogli Unità duplex 1650-Blatt-Hochkapazitäts-Zuführung 550-Blatt-Zuführung Duplexeinheit Alimentador de alta capacidad de 1.650 hojas Alimentador de 550 hojas...
Page 42 All manuals and user guides at all-guides.com Installing a new imaging unit requires some toner to prime the unit, reducing toner life expectancy. Subsequent toner cartridges will achieve normal life expectancy. L’installation d’une nouvelle unité imageur consomme un peu de toner pour l’amorçage de l’unité, ce qui réduit la durée de vie de la cartouche de toner. Les cartouches suivantes auront une durée de vie normale.
Page 43 Color Connection Visit the Color Connection web site for templates, tips, and tutorials designed especially for Xerox printers. You'll find everything from PowerPoint templates, calendars and greeting cards to articles on the effective use of color and forms to help you run your business. Visit...
Page 44 071-0690-01 RevA Copyright © 2002, Xerox Corporation. All Rights Reserved. Unpublished rights reserved under the copyright laws of the United States. XEROX®, The Document Company®, the stylized X®, Phaser® (color printers), Phaser™ (monochrome printers), CentreWare®, infoSMART™, and PhaserSMART™ are trademarks of Xerox Corporation.
