Pulsar SIPPER Manuel D'instructions

SPECS
Size: 4.3" x 4.3" x 6.9" (10.9 x 10.9 x 17.5 cm)
Input: 4.4-6.0 V 1 A
Battery Capacity: 1500 mAh
Voltage: 2.5 V / 3 V / 3.5 V / 4.2 V
Charging: USB-C
Atomizer Resistance: 1
KIT INCLUDES
1x Pulsar Sipper base
1x Glass dry cup
1x Mouthpiece
1x Airflow valve
1x Airflow silicone
1x Atomizer/cartridge cover
1x Wax atomizer
1x 510 connection
1x Dab tool/poker
1x USB-C charging cable
1x Glass dry cup
ASSEMBLY
Remove the atomizer/cartridge cover from the Sipper base and screw the wax atomizer or cartridge (not included)
into the 510 connection then replace the cover. The light around the touchpad will flash the current voltage to show
a successful connection has been made if the Sipper is already on. Put the two pieces of the airflow valve together
before inserting it into the bottom of the dry cup. Now place the dry cup on top of the cover, lightly pressing down
so there is a good fit. This should not require a lot of pressure.
LOADING
Remove the dry cup from the cover and then remove the cover from the base. With the wax atomizer connected,
load a small amount of concentrate into the atomizer. About a half grain of rice is all that is needed; be sure not to
overfill the atomizer. Then replace the cover and sit the dry cup back on top.
ATTENTION! Do not touch the coils with metal dab tools while the Sipper is working.
CHANGE VOLTAGE SETTINGS
Press the touchpad 3 times to selectyour voltage. Once you have your voltage selected press and hold the touch-
pad.
Voltages: Yellow - 2.5 V Blue - 3 V
USAGE
Press the touchpad with the tip of your finger 5 times to turn on the Sipper, the light around the touchpad will flash
to let you know it is on and the battery life.
Green - 100% - 70% Blue - 70% - 30%
Note: The Sipper will automatically turn off after 10 minutes of inactivity.
• Operating Wax Atomizer - With the Sipper turned on, press the touchpad 3 times to change your voltage. Once you
have your voltage selected, touch and hold the touchpad. You will hear the pump activate and see the vapor start
filling the dry cup. Once the dry cup is filled, pull the dry cup off the base, and inhale through the mouthpiece.
• Operating 510 Cartridge - Remove the wax atomizer and unscrew the 510 connection before inserting a 0.5 mL or
1 mL 510 cartridge to the 510 connection, then screw the 510 connection back into the base. Replace the cover and
sit the dry cup back on top. Press the touchpad 5 times to turn on the Sipper, the light around the touchpad will
flash to let you know it is on. Press the touchpad 3 times to select your voltage. Once you have your voltage
PAGE 1
INSTRUCTION
MANUAL
WAX
510
ATOMIZER
CONNECTION
DO NOT ADD WATER
Green - 3.5 V Red - 4.2 V
Red - 30% - 0%
PulsarShop.com
AIRFLOW
VALVE
POWER
BUTTON/
TOUCHPAD
CHARGING
PORT
PU-0648-23
