ASSEMBLY GUIDE & USER MANUAL
Ensure that the clamp is flushed
03
against the edge of the desk and fully
tighten the top screw clockwise to
anchor the clamp in place.
Note: Ensure you do not overtighten
the top screw.
Insert the Bottom Arm into the Clamp
04
Mount and the Upper Arm into the
Bottom Arm. Turn the thumb screws
attached clockwise to secure your
arms in place.
Position the VESA Plate over the
05
mounting holes of your monitor and
attach the plate using the VESA screws.
If your monitor's VESA position is
recessed, we recommend that you use
the stand off screws provided
to extend your VESA plate outwards.
Note: The VESA Plate has both 75 mm
and 100 mm hole patterns. Choose the
appropriate holes location for your
monitor.
5
STANDOFF
SCREW USAGE
