L-Acoustics ETR5 Mode D'emploi page 3

ETR5 U-BRACKET
The ETR5 is a U-bracket designed to attach a 5XT enclosure to a wall, a ceiling or a rigging structure.
Refer to the rigging manual dedicated to the 5XT for the rigging procedures and the safety limits.
EC DECLARATION OF CONFORMITY
L-ACOUSTICS ®
13 rue Levacher Cintrat
Parc de la Fontaine de Jouvence
91462 Marcoussis Cedex
France
States that the following product:
ETR5 U-bracket.
Is in conformity with the provisions of:
2006/42/EC: Machinery Directive
Applied rules and standards:
EN ISO 12100-1: 2004: Safety of machinery
DIN 18800: Steel Structures
BGV-C1 : German standard for overhead rigging
ETR5 SPECIFICATIONS
Description Rigging element for the 5XT enclosure
Dimensions
Weight 0.7 Kg
Established at Marcoussis, France, November 1
Christophe PIGNON, Research & Development Director
Material
W W W . L - A C O U S T I C S . C O M
w w w . l - a c o u s t i c s . c o m
Before installation, assess the mechanical
safety of a system by modeling it with
SOUNDVISION software.
steel with anti-corrosion coating
st , 2012.
