Porter Cable 690LR Manuel D'utilisation

Instruction Manual
Manuel d'Utilisation
Manual de Instrucciones
MODELS 690LR, 691, & 690LRVS AND 6931 PLUNGE BASE
®
General Safety Rules
Read all instructions. Failure to follow all instructions listed below may result in electric
shock, fi re and/or serious injury. The term "power tool" in all of the warnings listed below refers to your
mains-operated (corded) power tool or battery-operated (cordless) power tool.
SAVE THESE INSTRUCTIONS
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
fl ammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
anyadapter plugs with earthed (grounded) power tools. Unmodifi ed plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators, rang-
es and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock. Use only 3-wire extension cords that
have 3-prong grounding-type plugs and 3-pole receptacles that accept the tool's plug.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor
use. If an extension cord is to be used outdoors, it must be marked with the suffi x W-A or
W following the cord type designation. Use of a cord suitable for outdoor use reduces the
risk of electric shock. When using an extension cord, be sure to use one heavy enough to
carry the current your product will draw. An undersized cord will cause a drop in line voltage
resulting in loss of power and overheating. The following table shows the correct size to use
depending on cord length and nameplate ampere rating. If in doubt, use the next heavier
gauge. The smaller the gauge number, the heavier the cord.
Minimum Gauge for Cord Sets
Volts Total Length of Cord in Feet
120V 0-25
240V 0-50
Ampere Rating Gauge of wire in AWG units
From 10 to 12 amps 16
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the infl uence of drugs, al-
cohol or medication. A moment of inattention while operating power tools may result in
serious personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate condi-
tions will reduce personal injuries.
c) Avoid accidental starting. Be sure the switch is in the off-position before plugging in.
Carrying power tools with your fi nger on the switch or plugging in power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a
key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in mov-
ing parts. Air vents often cover moving parts and should also be avoided.
g) If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of these devices can reduce dust-
related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The cor-
rect power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before making any adjustments, chang-
ing accessories, or storing power tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the power tools operation. If dam-
aged, have the power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc., in accordance with these instruc-
tions and in the manner intended for the particular type of power tool, taking into ac-
count the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualifi ed repair person using only identical re-
placement parts. This will ensure that the safety of the power tool is maintained.
ADDITIONAL SPECIFIC SAFETY RULES
• Hold tool by insulated gripping surfaces when performing an operation where the cutting tool
may contact hidden wiring or its own cord. Contact with a "live" wire will make exposed metal
parts of the tool "live" and shock the operator.
• Use clamps or another practical way to secure and support the workpiece to a stable platform.
Holding the work by hand or against your body leaves it unstable and may lead to loss of con-
trol.
• Metal cutting with router: If using router for metal cutting, clean out tool often. Metal dust and
ROUTER
TOUPIES
CONTORNEADORES
www.porter-cable.com
Copyright © 2007 Porter-Cable
Instructivo de operacion,
centros de servicio y poliza de garantia.
ADVERTENCIA: Lease este instructivo antes de usarel producto.
A22440-02-06-07-Rev.A
26-50 51-100 101-150
51-100 101-200 201-300
16 14 12
chips often accumulate on interior surfaces and could create a risk of serious injury, electrical
shock or death.
• Never run the motor unit when it is not inserted in one of the router bases. The motor is not
designed to be handheld.
• Keep handles dry, clean, and free from oil and grease. This will enable better control of the
tool.
• Keep hands away from cutting area. Never reach under the workpiece for any reason. Keep
the router base firmly in contact with the workpiece when cutting. Hold the router only by the
handles. These precautions will reduce the risk of personal injury.
• Use sharp cutters. Dull cutters may cause the router to swerve or stall under pressure.
• Never touch the bit immediately after use. It may be extremely hot.
• Be sure that the motor has stopped completely before you lay the router down. If the cutter head
is still spinning when the tool is laid down, it could cause injury or damage.
• Be sure that the router bit is clear of the workpiece before starting the motor. If the bit is in con-
tact with the workpiece when the motor starts it could make the router jump, causing damage
or injury.
• Do not press spindle lock button while the motor is running. Doing so can damage the spindle
lock.
Wear appropriate hearing protection during use [ANSI S12.6 (S3.19)]. Under some con-
ditions and duration of use, noise from this product may contribute to hearing loss.
Some dust created by power sanding, sawing, grinding, drilling, and other construction
activities contains chemicals known to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• lead from lead-based paint.
• crystalline silica from bricks and cement and other masonry products.
• arsenic and chromium from chemically-treated lumber (CCA).
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated area, and work with approved safety equipment,
such as those dust masks that are specially designed to filter out microscopic particles.
Avoid prolonged contact with dust from power sanding, sawing, grinding, drilling, and
other construction activities. Wear protective clothing and wash exposed areas with soap and water.
Allowing dust to get into your mouth, eyes, or lay on the skin may promote absorption of harmful
chemicals.
Use of this tool can generate and/or disburse dust, which may cause serious and
permanent respiratory or other injury. Always use NIOSH/OSHA approved respiratory protection
appropriate for the dust exposure. Direct particles away from face and body.
ALWAYS USE SAFETY GLASSES. Everyday eyeglasses are NOT safety glasses.
Also use face or dust mask if cutting operation is dusty. ALWAYS WEAR CERTIFIED SAFETY
EQUIPMENT:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3)
• ANSI S12.6 (S3.19) hearing protection
• NIOSH/OSHA/MSHA respiratory protection
SYMBOLS
The label on your tool may include the following symbols. The symbols and their definitions are as
follows:
V....................... volts
Hz .................... hertz
min .................. minutes
............... direct current
.................... Class I Construction
(grounded)
..................... Class II Construction
(double insulated)
BPM ..............beats per minute
SAVE THESE INSTRUCTIONS
MOTOR
Do not operate your tool on a current on which the voltage is not within correct limits.
Do not operate tools rated A.C. only on D.C. current. To do so may seriously damage the tool.
OPERATION
To reduce the risk of injury, turn unit off and disconnect it from power source before
installing and removing accessories, before adjusting or when making repairs. An accidental start-up
can cause injury.
Use router bits with a diameter larger than 2-1/2" ONLY when the speed control is set
between 10,000 and 13,000 RPM. The maximum diameter bit is 3-1/2".
INSTALLING THE BIT (1001 BASE)
To reduce the risk of injury, turn unit off and disconnect it from power source before
installing and removing accessories, before adjusting or when making repairs. An accidental start-up
can cause injury.
To remove the motor unit from the base unit:
(a) Open the clamp (A) Fig. 1.
(b) While holding the base, turn the power unit COUNTER-CLOCKWISE until the lower pin (B)
in the motor housing is disengaged from groove in base.
(c) Lift the power unit free from the base unit.
2. Clean and insert the shank of the bit into the collet until the shank bottoms, then back it out
approximately 1/16".
3. Lay the power unit on its side on a bench with the collet pointing AWAY from you.
4. Place one wrench on the flats of the chuck with the opposite end of the wrench resting on the
bench to your left (Fig. 2).
5. Place the other wrench on the collet and tighten COUNTER-CLOCKWISE. Tighten firmly.
6. To remove the bit, reverse the procedure.
Avoid possible damage to the collet. Never tighten the collet without a bit.
INSTALLING THE MOTOR
To reduce the risk of injury, turn unit off and disconnect it from power source before
installing and removing accessories, before adjusting or when making repairs. An accidental start-up
can cause injury.
1. Open the clamp (A) Fig. 1 and set the power unit in the base unit.
2. Align the lower pin of the power unit (B) Fig. 1 with the groove in the base.
3. Rotate the power unit CLOCKWISE into the base until the upper guide pins are set in the groove of
the base.
4. Close the clamp.
ADJUSTING THE DEPTH OF CUT
To reduce the risk of injury, turn unit off and disconnect it from power source before
installing and removing accessories, before adjusting or when making repairs. An accidental start-up
can cause injury.
1. Open the clamp (A) Fig. 3.
2. Hold the base (E) and turn the power unit (F) Fig. 3 counter-clockwise until the tip of the bit is above
the bottom of the base.
3. Set the tool on a flat surface.
4. Turn the power unit (F) Fig. 3 clockwise until the bit touches the work.
5. Close the clamp (A) Fig. 3.
6. Rotate the depth adjusting ring (B) Fig. 3 until the zero-line (C) is opposite the index line (D) on
the housing.
7. Open the clamp (A) Fig. 3.
8. Tip the router so that the bit is clear of the work surface. Turn the power unit (F) Fig. 3 clockwise
until the index line (D) on the motor housing reaches the desired depth indicated on the ring.
9. Close the clamp (A) Fig. 3.
NOTE: Setting the index line to 1/4" on the ring means the cutting edge of the bit is exposed 1/4"
below the base.
ADJUSTING THE SUB-BASE ALIGNMENT (Plunge Base)
To reduce the risk of injury, turn unit off and disconnect it from power source before
installing and removing accessories, before adjusting or when making repairs. An accidental start-up
can cause injury.
Applications using a template guide require the bit to be centered in the guide. This, in turn, requires
the center hole in the sub-base to be in line with the collet of the motor unit. Your model has an adjust-
able sub-base that has been aligned at the factory. The fixed-base router comes with the large hole.
1. Loosen the sub-base mounting screws (C) Fig. 4 just enough to allow the sub-base (D) to move.
2. Open the clamp (A) and adjust the power unit so that the collet nut (B) engages the center hole
in the sub-base (D). Allow the sub-base to center itself on the collet nut. Close the clamp.
3. Tighten the sub-base mounting screws (C) Fig. 4 securely.
INSTALLING THE MOTOR (6931 Plunge Base)
To reduce the risk of injury, turn unit off and disconnect it from power source before
installing and removing accessories, before adjusting or when making repairs. An accidental start-up
can cause injury.
1. Support the motor clamp (D) Fig. 5 and loosen the motor clamp screw (A) Fig. 5 approximately
1/2" with the hex wrench (furnished).
2. Insert the motor unit into the base with the switch positioned at the front of the left handle. Align the
four pins (A) Fig. 7 (two of which are shown) in the motor case with the slots (B) Fig. 6 in the base.
3. Seat the motor in the base and tighten the motor clamp screw.
REMOVING THE MOTOR
To reduce the risk of injury, turn unit off and disconnect it from power source before
installing and removing accessories, before adjusting or when making repairs. An accidental start-up
can cause injury.
1. Remove the clamp screw (A) Fig. 5, flat washer (B), lock washer (C), and clamp-locking nut (A)
Fig. 6.
2. Insert the hex wrench (A) Fig. 8 to contact the locking plate (B) Fig. 6. Tap lightly to release and
remove the locking plate.
3. Slide the motor out of the base.
4. Reattach the clamp screw, lock washer, flat washer, locking plate and clamp locking nut to the
base and tighten lightly.
A...........................amperes
W .........................watts
.......................alternating current
n o .........................no load speed
.........................earthing terminal
........................safety alert symbol
.../min .................revolutions or reciprocations
per minute
