8. Spare parts list HORSE
Reference Art. No.
1 + 2
3 CR603
4 CR604
5 CR605
6 CR606
7 CR607
8 CP608
9 CR609
10 CR610
11 CR611
12 CR617
13 CR616
14 CR613
15 CR615
16 CR624
17 CR625
18 CR626
3-18 18930
13-15 CR627
22 CR618
23 CR623
24 CP602
25 CP603
26 CO605
27 CO607
28 CO608
28 CO699
29 CO609
30 CP610
31 CO611
32 CO612
33 CO640
34 CO614
35 CO615
36 CO616
37 CP601
37 CO622
23-37 CP620
23-37 CP621
38 CR621
39 CR622
without illu. 1850488
without illu. CR699
without illu. CO600
without illu. 18946
without illu. 18945
See separate spare parts drawing!
Amount Description
1 Shearing blade replacement depends on application, ask your local retailer!
2 Screw for bottom cutter
1 Blade
2 Shaft screw for blades
6 Blade spring leaf
2 Spacer plate for blade spring
1 Spur gear wheel with shaft
1 Eccentric square blade block
1 Shearing head housing with bush
1 Countersunk screw for shaft, M3x8 mm
2 Screw for blades, rear, M5x12 mm
1 Spring bridge
1 Adjusting screw with plug
1 Screw for spring bridge
1 Bush, large, 12x13.5
1 Bush, small, 6x10
1 Sleeve 14x18
1 Shearing head complete, without cutter
1 Regulating screw replacement set
2 Screw for shearing head fastening
2 Carbon brush with spring
1 Anchor complete with bearing for 120 W motor
1 Stator for 120 W motor
1 Carbon brush holder set, left+right
2 O ring for anchor ball bearing
1 Mains connecting cable with plug
1 Mains connecting cable with plug, English
1 Mains unit switch
1 120 W motor safety switch
1 Suppression capacitor
1 Cord
1 Motor housing, two-part
4 Screw 4x12 for gearing
6 Housing screw 4x20
1 Carrier loop
1 Gear 17/32 teeth for 120 W motor
1 Plastic cog wheel, 32 teeth for CO601
1 120 W drive motor complete
1 120 W drive motor complete, English
1 Air filter, right
1 Air filter, left
1 Shearing machine oil constanta 100 ml
1 Operating instructions, Beef + Horse, DIN A5
1 Plastic case, incl. insert
1 TX20 screwdriver for Philips screw
1 Screwdriver for SM cutter
