Indoor Unit
Inlet grille
Air filter
Vertical flap
Power indicator
Use remote controller to
Lights up when unit starts.
adjust up and down air
flow.
(Don't
adjust
it
manually.)
Actual inlet grille may vary from the one shown in the manual according to the product purchased.
Outdoor unit
2
1
ASD9UCB ( DS-9UCB DOS-9UCB )
1
OUTLET
2
INLET
3
CONNECTING PIPING AND ELECTRICAL WIRING
4
DRAIN HOSE
54
PARTS AND FUNCTIONS
Timer mode indicator
Lights up when Timer operation
is selected.
3
4
Test running switch (manual)
Used only for test running in cooling
when room temp. is below 16ºC.
Don't use it in normal operation.
Emergency switch (manual)
Used when remote controller is lost or
defective. Unit will run temporarily.
Remote signal receiver
A beeping sound is generated when
a signal from remote controller is
received.
Operation mode indicator
Lights up during compressor
running.
2
2
1
3
4
