UNFIX 800 EGF MOUNTING (CONTINUATION)
Equipped with a multi-position tilting system, Unifix brackets allow for an optimization of your
•
panel's performance depending on the chosen orientation.
10°
40°
• Attach the arms to the previously assembled foot.
X2
25
Electrical performance as a function of inclination
and panel orientation
0°
East 93%
South-East 93%
South 93%
South West 93%
West 93%
X2
www.uniteck.fr
30° 60° 90°
90% 78% 55%
96% 88% 66%
100% 91% 68%
96% 88% 66%
90% 78% 55%
20°
50°
M10x25
X12
EN
30°
60°
D10 M10
X12 X12
