EN
CHARACTERISTICS
A sprayer made of top quality materials not subject to attack by treatment products, including copper derivatives. Adjustable
nozzle. Adaptor for accessories. Chrome plated directional brass lance. Metal handle. Filter on lance. Handle fastener. Hose
with nuts, without clamps. Right-angle chamber elbow. Guide bush. Chamber locking cover with sealing gasket. Highly resistant
chamber. Original viton seal. Stainless steel balls in valve and sleeve. Tank cover with non drip valve. Large filling filter with indicator
of contents. Strong polyethylene tank with level indicator, ergonomic shape and back separator. Hook-directed, adjustable,
anticorrosive and non-slip straps. Mechanical agitator. Shockproof anticorrosive base.
Fastening device for lever, lance and arm to facilitate transport and storage.
Box in the base for carrying and storing spares and accessories.
Supplied with an interchangeable herbicide nozzle (718), doser (674), pressure regulator (997) and retainers (133)(497).
STARTING-UP
1) Attach hose (703) to lance (705) and elbow chamber (125).
2) Release cover (704) and pour in liquid to be sprayed without removing filter (105).
3) Attach the straps (1375) and (1376) and adjust them with the device fitted to the back (see last page for strap attachment).
4) Move the lever (711) 8-10 times by gripping the handle (126) to obtain pressure. Operate the handle (706) and regulate the nozzle
(100) until reaching the desired pressure and spray, bearing in mind that 10-14 strokes per minute give a flow rate of 0.6-0.9
litres/minute.
NOTE: The sprayer leaves the factory set for using the lever with the left hand (minimum effort) and the lance with the right one
(greater treatment accuracy). If you wish to work the other way around, proceed as follows : turn elbow chamber (125) to orient the
hose (703). Remove bushing (338) by inserting a suitable screwdriver in slot A -placed below an indicating rib- and turning it. Place
lever (711) in the centre hole in the base. Invert the straps, place the adjustable strap (1375) in the window provided on the base,
opening it with a knife. The (1376) strap (1375) should be placed in its housing.
MAINTENANCE-MOST FREQUENT MALFUNCTIONS AND THEIR SOLUTIONS
1) Clean the sprayer and the circuits of liquid, including the filters, after each working day. This can be done by working the device
with clean water, adding a little household detergent if desired.
2) To change the retainer. Release guide nut (124), extract the agitator (106) from inside, remove the chamber (713), unscrew the
valve (118) and replace the viton seal (120) with a new one. Re-assemble by following the above instructions in reverse order.
3) Nozzle (100) obstructed. Clean with water jet or non metallic instruments.
4) Handle (706) jammed. Apply a few drops of oil between pipe (702) and handle (706).
5) Filter (112) dirty. Remove from grip (113) and clean.
6) Store the sprayer under cover, avoiding freezing temperatures and extreme heat.
SAFETY STANDARDS FOR HANDLING PHYTO-SANITARY PRODUCTS
a) Storage. *Store products in an exclusive area. This should be well ventilated, locked and out of reach of children and animals.
*Keep products in their original packaging and use the same place to store mixing, preparation and application utensils.
b) Preparation of product. *Check that the product and treatment equipment are not out of date, and are in good condition. *Read
and follow the instructions on product labels and in manuals. *Use suitable utensils for mixing and preparing, and mark them
correctly. *After preparation, wash your hands and face. *Dispose properly of empty packages and leftover product.
c) Performing treatment. *Use suitable protective equipment. *Avoid contact with the skin and eyes, and do not eat, drink or smoke.
Do not apply in windy conditions or against the wind. *Avoid any product drifting into adjacent land and crops. Avoid any drift
into springs, streams, lakes, etc.
d) After treatment. *Thoroughly clean the treatment machinery. *Wash yourself and your clothes.
e) Advice in case of poisoning. *Go to the doctor with the product label, or take the affected person to the nearest hospital. *Do not
use home remedies, and in all cases wash the affected skin areas with plenty of cool water.
f) General precautions. *Strictly follow the norms on the labels of products marked "dangerous" and "poisonous". *Comply with the
application time and expiry date of each product. *Do not spray in very hot weather. *Take care near electrical installations. *Do
not use flammable materials or materials which might originate combustion processes.*These sprayers are to be used only with
herbicides, insecticides and fungicides for plants. *Sprayers must be safety tested at least once a year by a specialist. At the time
of manufacturing, the manufacturer knows of no harmful influences on the material of which the device is made by anti-parasite
products authorized by the German Federal Institute of Biology. *Use only the original manufacturer´s Ø 6-12 mm. spray hose.
WARRANTY
Our goods have warranty, from the date of purchase by the user, against any manufacturing or material defect. The warranty is
strictly limited to free replacement of parts that our services consider defective. The warranty shall not apply in case of improper
use of our materials, disassembly and/or alterations performed to our devices, and to those parts of normal wear and tear that
require maintenance The warranty shall not apply in case of negligence, imprudence and irrational use of the material. Dispatch and
transportation costs of parts under warranty as well as workmanship that were not performed in our factory shall be borne by the
user. To invoke this warranty, send us the part subject matter of the claim, carriage free, together with the receipt or the purchasing
invoice.
