7. For door thickness X: prepare threaded rods and spindle
7. For door thickness X: prepare threaded rods and spindle
*X
13
14 *X
PH2
15 *X
2× L1: door thickness - 8 mm (±3 mm)
16 *X
2× L2: door thickness + 8 mm (±3 mm)
10 / 64
PegaSys Door Handle 4.1 Downward installation
PH2
