System Map: Bottom & Rear Views
1
1
1
1. Vent
2. HDMI-Out Port
3. Mini DisplayPort
4. USB 3.0 (USB 3.1 Gen 1) Port
5. DC-In Jack
1
1
2 3 4 5
Figure 13
Bottom & Rear Views
1
To prevent your computer from over-
heating make sure nothing blocks
any vent while the computer is in
use.
Battery Removal
Note that the built-in battery is not
user removable. Removing the bat-
tery will violate the terms of your
warranty.
Bottom Cover Removal Warning
Do not remove any cover(s) and/or
screw(s) for the purposes of device
upgrade as this may violate the
terms of your warranty.
1
If you need to replace/remove the
hard disk/RAM/battery etc., for any
reason, please contact your distribu-
tor/supplier for further information.

Overheating
