Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
▲Specify Finish / Especifíque el Acabado / Précisez le Fini
ADA COMPLIANT GRAB BAR WHEN
INSTALLED PER THE ACCESSIBILITY
GUIDELINES OF THE ACT.
ADA DE CUMPLIMIENTO CON
LA BARRA DE AGARRE AL
INSTALARSE SEGÚN LAS PAUTAS DE
ACCESIBILIDAD DE LA ACT.
BARRE D'APPUI CONFORME ADA
LORSQU'ELLE EST INSTALLÉE
PAR LES DIREC TIVES SUR
L'ACCESSIBILITÉ DE L'OPÉRATION.
?
www.deltafaucet.com
1-800-345-DELTA (3358)
customerservice@deltafaucet.com
You may need
Usted puede necesitar
Articles dont vous pouvez avoir besoin:
Drill Bit
8/20/2018
#2 & #3 Phillips
GRAB BAR
102831
BARRA DE APOYO
BARRE D'APPUI
41612p, 41618
41712p, 41718p, 41724p, 41736p, 41742p
41812p, 41818p, 41824p, 41836p, 41842p
41912p, 41918p, 41924p, 41936p, 41942p
Parts and Hardware Included
Piezas y hardware incluidos
Pièces et matériel inclus
102831
1
, 41624
, 41636
Set of Mounting Hardware
Six (6) #10 x 2-1/2" Wood Screws
Juego de Herramientas de Instalación
Seis (6) #10 x 2-1/2" Tornillos de Madera
Set de Matériel de Montage
Six (6) Vis à Bois #10 x 2-1/2"
Wall Anchor (1)
Anclaje de pared (1)
Ancrage mural (1)
, 41642
102831 Rev. B

Publicité

loading

Sommaire des Matières pour Delta 41618

  • Page 1 GRAB BAR 102831 BARRA DE APOYO BARRE D’APPUI 41612p, 41618 , 41624 , 41636 , 41642 ▲ ▲ ▲ ▲ 41712p, 41718p, 41724p, 41736p, 41742p 41812p, 41818p, 41824p, 41836p, 41842p 41912p, 41918p, 41924p, 41936p, 41942p Write purchased model number here.
  • Page 2 Top view horizontal mount Side view vertical mount Vista superior montaje horizontal Vista lateral montaje vertical Vue de face installation Vue latérale installation horizontale verticale Exposed mount grab bar Concealed mount grab bar Barra de soporte de montaje expuesto Wood screw Barra de soporte de montaje oculto Tornillopara madera Barre d'appui avec fixation non...
  • Page 3 WALL ANCHOR MOUNTING DIRECTIONS DO NOT install supplied wall anchors into wallboard less than ½” or greater than 2 ½” thick. DO NOT install supplied wall anchors into wallboard that has been subjected to water damage or decay. DO NOT install supplied wall anchors into a wood stud. NOTE: Opposing end will need to be mounted using the Stud Mounting Directions in Section 1, steps 7-9.
  • Page 4 Type 1 Type 2 Adapter Adaptador Adaptateur Hold on tightly to the flange and keep pressure on the bar Turn and tighten the screw while applying pressure on the bar to keep it upright. Tighten the screw till the flange plate is flush against the wall and is behind the wall to ensure that the bar stays upright with the longest part of the bar pointing upward.
  • Page 5 TOP VIEW HORIZONTAL MOUNT VUE DE FACE INSTALLATION HORIZONTALE VISTA SUPERIOR MONTAJE HORIZONTAL NORMALLY 42" CENTER-TO-CENTER ENTRAXE DE 1067 cm NORMALEMENT NORMALMENTE 1067 CM CENTRO A CENTRO wood wall stud montante de pared de madera poteau d'ossature murale en bois FRONT VIEW FRONT VIEW ANGLE MOUNT...
  • Page 6 p Specify Finish / Especifíque el Acabado / Précisez le Fini 41612p, 41618p, 41624p, 41636p, 41642p 41712p, 41718p, 41724p, 41736p, 41742p RP100076 Base (2), Set Screw (2) & Allen Wrench 3 mm (1) Base (2), Tornillo de Ajuste (2) y Llave Allen, 3 mm (1) Embase (2), Vis (2) et Clé...
  • Page 7 WARNING GRAB BAR MAY NOT PROVIDE DESIGNED AMOUNT OF SUPPORT UNLESS THESE INSTALLATION THE FOLLOWING STEPS REQUIRE DRILLING INTO THE WALL. When drilling into the wall, INSTRUCTIONS ARE STRICTLY FOLLOWED. For proper installation, at least one end of Grab Bar MUST exercise care to avoid any electrical wiring or plumbing that may be located behind the wall.
  • Page 8 Si la reparación o el reemplazo no es práctico, Delta Faucet Company puede optar por reembolsarle el precio de compra a cambio de la devolución del Limitación de Daños Especiales, Incidentales o Consiguientes.
