Coding the chime and bell button::
1. Before coding, select your preferable bell tone (refer to "Volume setting/Melody selection").
2. Press the "Volume" button on the chime for 5 seconds. You will hear a ding-dong and the LED starts
blinking, to signalise that the coding mode is active.
3. Press the bell push, to send a signal to the chime. If the coding was successful, the chime will
automatically play back the bell tone.
Note:
• The coding mode is automatically terminated after concluding the coding.
• The coding mode is only active for 5 seconds.
• The coding mode is always only available for one receiver (chime) and transmitter
(bell push, motion detector, window contact) simultaneously. Repeat the above-mentioned coding if
you would like to code multiple receivers/transmitters.
• You can assign a different bell tone to each transmitter when coding and in doing so, create a call
differentiation.
• Up to 20 receivers (chime) can be assigned to one transmitter (bell push, motion
detector, window contact). Refer to "Compatible Products".
• Up to 20 transmitters (bell pushes, motion sensors, window contacts)
can be assigned to one receiver (chime). Refer to "Compatible Products".
Deleting the coding:
Press the "Melody forward" button for 5 seconds, to reset the chime to the factory settings. When
the chime plays back ding-dong and the LED blinks, resetting was successful.
Note: The coding between chime and window contact exists, until you delete the coding as
described above. Even if you remove the batteries.
chime side elevation
volume
Melodies
backwards
Melodies forward
Push mounting
plate upwards for
disassembly.
chime rear side
bell push rear side
Suspension clip
battery
compartment
battery
compartment
