Ryobi RDD18X Mode D'emploi page 3

Safety, performance, and dependability have been given
top priority in the design of your drill driver.
INTENDED USE
The drill driver is intended to be used only by adults who
have read and understood the instructions and warnings
in this manual, and can be considered responsible for their
actions.
The product is intended for drilling into various materials,
including wood, metal, and plastics using a drill bit having
a shank diameter of less than 13 mm. The product can
be used to drive and remove screws and bolts using an
appropriate bit.
The product is intended for consumer use only.
Do not use the product for any other purpose. Use of the
in a hazardous situation.
WARNING! Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
Save all warnings and instructions for future reference.
DRILL DRIVER SAFETY WARNINGS
SAFETY INSTRUCTIONS FOR ALL OPERATIONS
Use the auxiliary handle(s). Loss of control can cause
Hold the power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory or fasteners may contact hidden wiring.
Cutting accessory or fasteners contacting a "live" wire
may make exposed metal parts of the power tool "live"
and could give the operator an electric shock.
SAFETY INSTRUCTIONS WHEN USING LONG DRILL
BITS
Never operate at higher speed than the maximum
speed rating of the drill bit. At higher speeds, the
bit is likely to bend if allowed to rotate freely without
Always start drilling at low speed and with the bit
tip in contact with the workpiece. At higher speeds,
the bit is likely to bend if allowed to rotate freely without
Apply pressure only in direct line with the bit and do
not apply excessive pressure. Bits can bend causing
ADDITIONAL SAFETY WARNINGS
Clamp workpiece
damage.
Dust created by operating the product can cause
with filters suitable for protecting against particles from
the material being worked on.
periods, ensure you take regular breaks.
Switch off the product immediately if the bit stalls. Do
not switch on the product again while the bit is stalled,
with a clamping device.
as doing so could trigger a sudden recoil with a high
reactive force. Determine why the bit stalled and rectify
this, paying heed to the safety instructions.
The possible causes may be:
– it is tilted in the workpiece
– it has pierced the workpiece
– the product is overloaded
Ambient temperature range for tool during operation is
between 0°C and 40°C.
Ambient temperature range for tool storage is between
0°C and 40°C.
The recommended ambient temperature range for the
charging system during charging is between 10°C and
38°C.
ADDITIONAL BATTERY SAFETY WARNINGS
damage due to a short circuit, never immerse your
tool, battery pack or charger in fluid or allow a fluid to
flow inside them. Corrosive or conductive fluids, such
as seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a short
circuit.
Ambient temperature range for battery during use is
between 0°C and 40°C.
Ambient temperature range for battery storage is
between 0°C and 20°C.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and labelling
when transporting batteries by a third party. Ensure that
no batteries can come in contact with other batteries
or conductive materials while in transport by protecting
exposed connectors with insulating, non-conductive caps
or tape. Do not transport batteries that are cracked or
leaking. Check with the forwarding company for further
advice.
KNOW YOUR PRODUCT
See page 56.
1. Gear selector
2.
3. Keyless chuck
4. Direction of rotation selector
5. Variable speed switch trigger
6. Handle, insulated gripping surface
7. LED light
8. Battery port
9. Auxiliary handle, insulated gripping surface
10. Screw driver bit
11. Operator's manual
12. Battery pack
13. Charger
MAINTENANCE
The product should never be connected to a power
cleaning, performing maintenance, or when the product
is not in use. Disconnecting the product from the power
supply will prevent accidental starting that could cause
Original Instructions
