DESCRIPTION
10-435-12
PVC WINDOW
(in frame)
12-176-12
PVC WINDOW
for HALF FRAME
A-3 1/2
10-493
PVC WINDOW
(replacement
material only)
85-417-P
ROUND SPLINE
FOR PVC
WINDOW
15-123-12
PIN FOR PVC
WINDOW
13-055
PC WINDOW (for
sliding door)
12-174-12
MOSQUITO
SCREEN (in
frame)
12-175-12
MOSQUITO
SCREEN FOR
HALF FRAME A-
3 1/2
*NOT INCLUDED IN THE BOX
DESCRIPTION COLOUR
SPRAY PAINT
SAND
PAINT PEN
AVAILABLE REPLACEMENT PARTS
DRAWING
PART #
11-699
18-245
DESCRIPTION
85-014
REPLACEMENT
SCREENING (no
frame)
85-417-S
ROUND SPLINE
FOR SCREENING
11-824-12
BOTTOM PLASTIC
PANEL (for wall
panels)
11-825-12
BOTTOM PLASTIC
PANEL (for doors)
12-173-12
BOTTOM PLASTIC
PANEL FOR HALF
FRAME A-3 1/2
15-097-12
DOOR WHEEL
ASSEMBLY
10-458
REPLACEMENT
WEATHERSTRIP
124"
15-125-12
MOUNTING
BRACKET FOR
RAFTER (U-3)
DRAWING
