This couple (thermostat BT-x02 and receiver BT-WR02 H&C RF) can also be managed by a Central unit BT-CT02 RF to have a full
control of your heating installation from one point. In that case, the receiver works always in automatic regulation mode for the
heating/cooling switch. With the central unit, it is possible to pair the receiver in "Regulation/heating" mode and in "Hydraulic circuit"
mode. It is not possible to pair the receiver in lighting mode or ON/OFF mode.
You can access to the general leaflet of the system on http://www.wattselectronics.com/
With a BT-D02 RF and BT-DP02 RF it is possible to configure the receiver in manual mode, heating mode, cooling mode or automatic
mode (Please refer to the BT-Dx02 RF leaflets).
In all cases, the receiver is making cooling only in comfort mode. All other modes (Reduced, anti-freeze, auto in Reduced) forbid the
cooling regulation.
In case of set point modification, a delay of 5mn is always applied before switching from cooling to heating or heating to cooling. In
automatic regulation, a dead band of ± 1°K with timer is applied before switching from heating to cooling or from cooling to heating.
Compatibility matrix:
Pairing
Regulation
BT-WR02 RF mode
The receiver is delivered with 2 outputs in free contact mode. To trigger the outputs in live contact, linked the live on 1 point of each
connector using the cable supplied in the box.
BT-WR02 H&C RF Wall Receiver
1. Presentation
BT-WR02 H&C RF
The
hydraulic heating regulation or cooling regulation.
It embeds a proportional regulation with a time cycle of 10mn. Hysteresis regulation is not
supported.
• The heating relay is used to control a boiler in free contact or a valve or an electric
radiator in live contact. (Available with all thermostats of the BT-x02 range)
• The cooling relay is used to manage an actuator for a cold water circuit. (Not available
with BT-A02 RF thermostats)
BT-CT02 RF
Regulation/
X
Heating
ON/OFF
Lighting
Hydraulic
X
circuit
Heating
Cooling
Manual
Auto X
receiver is a Wall mounting receiver, specially designed to control
