CHIMNEY TOP DRAFT INDUCER

The Type "C" Chimney Top Draft Inducer is designed for installation on smoke

pipes, Type" B" vents, Type "L" vents and factory built Class "A" chimneys. The

Type "C" Draft Inducer is installed on the top of the vent system outside of the

building.

Model: Type "C"

English .......Page 1

Français .....Page 4

Espanõl ......Page 6

Sommaire des Matières pour Field Controls 04052900

Page 1 All manuals and user guides at all-guides.com CHIMNEY TOP DRAFT INDUCER Model: Type “C” The Type “C” Chimney Top Draft Inducer is designed for installation on smoke pipes, Type” B” vents, Type “L” vents and factory built Class “A” chimneys. The Type “C”...
Page 2 All manuals and user guides at all-guides.com INSTALLATION “B” ”L” MOKE VENTS AND VENTS 1. Insert the Type “C” housing directly into the vent pipe. (See Figure 1) 2. Fasten housing to vent pipe using three (3) sheet metal screws, located 120º apart.
Page 3 All manuals and user guides at all-guides.com WIRING 1. Remove the four (4) screws that hold the conical rain cover in place.This will expose the motor juction box. CAUTION: Disconnect electrical power when wiring draft inducer. 2. Wire the draft inducer in accordance with the National Electrical Code and applicable local codes. UNIT MUST BE GROUNDED! Check ground circuit to make certain the unit has been properly grounded.
Page 4 All manuals and user guides at all-guides.com INDUCTEUR DE TIRAGE DE TETE DE CHEMINEE Model: Type “C” INSTALLATION "B" "L" UYAUX DE CHEMINÉE ÉVENTS DE TYPE ET ÉVENTS DE TYPE 1. Insérer le boîtier de type "C" directement dans le tuyau de ventilation. (Voir Le Schéma 1) 2.
Page 5 All manuals and user guides at all-guides.com CÂBLAGE 1. Retirer les quatre vis qui maintiennent le capuchon conique en place, de façon à exposer la boîte de jonction du moteur. ATTENTION: Couper l’alimentation électrique avant de câbler l’inducteur de tirage. 2.
Page 6 All manuals and user guides at all-guides.com INDUCTOR DE DIRCULACIÓN PARA LA PARTE SUPERIOR DE LA CHIMENEA Modelo: Tipo “C” INSTALACIÓN “B” “L” ONDUCTOS DE HUMO RESPIRADEROS TIPO Y RESPIRADEROS TIPO 1. Introduzca el bastidor tipo “C” directamente en el tubo de ventilación. (Ver Figura 1) 2.
Page 7 All manuals and user guides at all-guides.com CABLEADO 1. Saque los cuatro (4) tornillos que sostienen el capuchón cónico en posición. Esto dejará expuesta la caja de empalme del motor. PRECAUCIÓN: Desconecte la corriente eléctrica cuando conecte los cables del inductor de circulación. 2.
Page 8 (See Figure 8) 9. Re-attach the cap of the Type C unit. (See Figure 9) Figure 3 Figure 2 Figure 1 Figure 6 Figure 5 Figure 4 Figure 9 Figure 7 Figure 8 Page 8 PN 04052900 Rev C 10/06...
