PARTS
Handle
REPLACEMENT OF HANDLE WITHOUT NIGHTLIGHT
Handle and Mirror Screws-071819.pdf 1 7/19/2019 11:20:08 AM
1. Remove the four hex screws holding the handle as shown in Image 1A and remove handle. The removed handle is no longer
required.
2. Place new handle in the same position as the original with the mounting flange behind the door frame, and re-install the hex screws
that were removed in Step 1.
1
C
M
Y
CM
MY
CY
CMY
K
© 2019 Robern, Inc. 701 N. Wilson Ave. Bristol, PA 19007 U.S.A.
800.877.2376
www.robern.com
Installation instructions
Uplift
3/32 Allen Key
1A
Note: View is from inside the cabinet for screw location
Handle screws
1
Tech Handle Upgrade
®
Handle screws
Mirror screws
Part no. 209-1315-A rev. 08/21/19
Uplift Tech Handle
