TABLE OF CONTENTS
Tools Needed - 2
Parts - 2
Model Numbers - 2
Installing the Mirror - 3
Use and Maintainance - 6
Warranty - 6
GENERAL INFORMATION
This instruction sheet contains information on how to install a Modular Mirror. This product line comes in various sizes. Refer to specific
model numbers for dimensions.
Read the specific instruction for how your wall mirror will be mounted.
Save these instructions for future use and reference. An improper installation voids the warranty.
Carefully inspect the mirror for damage. Installed products cannot be returned.
If you experience any problems with your wall mirror, contact your dealer or Robern directly.
Limited Warranty — One Year Term
© 2020 Robern, Inc. 701 N. Wilson Ave. Bristol, PA 19007 U.S.A.
800.877.2376
www.robern.com
MODULAR MIRROR
Installation instructions - Save these instructions
CB-MODM1230FP
CB-MODM1630FP
CB-MODM2030FP
CB-MODM2430FP
CB-MODM1236FP
CB-MODM1636FP
CB-MODM2036FP
CB-MODM2436FP
CB-MODM1240FP
CB-MODM1640FP
CB-MODM2040FP
CB-MODM2440FP
1
CB-MODM1230FB
CB-MODM1630FB
CB-MODM2030FB
CB-MODM2430FB
CB-MODM1236FB
CB-MODM1636FB
CB-MODM2036FB
CB-MODM2436FB
CB-MODM1240FB
CB-MODM1640FB
CB-MODM2040FB
CB-MODM2440FB
Part no. 209-1361 10/07/2020
Modular Mirror
