DIMENSIONS FOR 3SWCE & 3SWCCE GLASS DOOR
ROUGH IN OPENING DIMENSIONS, FOR 3SWCE & 3SWCCE GLASS DOOR
** 34" to 35"
(86.36 to 88.9cm)
*24" (61 cm)
standard cabinet
All manuals and user guides at all-guides.com
16-9/16"
(39.52cm)
14-7/8"
(37.78cm)
33-3/4" to 34-3/4"
(85.7 to 88.3 cm)
3" to 4"
(7.62 to 10.2cm)
depth
15" (38.1 cm)
37"
(93.98cm)
25-7/32
(64.06cm)
23-9/32
(59.13cm)
21-3/16"
(53.82cm)
Electrical Requirements: A grounded 115 volt, 15 amp dedicated
circuit is required.
Power outlet can be located in the back wall behind unit. Add 1"
to depth for thickness of plug, or recess outlet 1" into the wall.
Power outlet can also be installed in adjacent cabinetry with a
cutout for routing of power cord. Follow all local building codes
when installing electrical and unit.
Product weight = 130 lbs. (59.1 kg.)
* Depth dimension may vary depending on
each individual installation.
** Minimum rough in opening required is to be
larger than the adjusted height of the cabinet.
8
