DIMENSIONS FOR 6SDZE GLASS OVERLAY DOOR
(60.66cm)
RECOMMENDED ROUGH IN OPENING FOR 6SDZE GLASS OVERLAY DOOR
** 34" to 35"
(86.36 to 88.9cm)
*24" (61 cm)
standard cabinet
depth
24" (61.1 cm)
All manuals and user guides at all-guides.com
23-1/32"
(58.5cm)
23-7/8"
33-3/4" to 34-3/4"
(85.7 to 88.3cm)
3" to 4"
(7.62 to 10.2cm)
18
46-1/4"
(117.48cm)
23-19/32"
(59.92cm)
21-9/16"
(54.76cm)
22-29/32"*
(58.19cm)
Electrical Requirements: A grounded 115 volt, 15 amp dedicated
circuit is required.
Power outlet can be located in the back wall behind unit. Add 1"
to depth for thickness of plug, or recess outlet 1" into the wall.
Power outlet can also be installed in adjacent cabinetry with a
cutout for routing of power cord. Follow all local building codes
when installing electrical and unit.
Product weight = 136 lbs. (61.8 kg.)
* Depth dimension may vary depending on
each individual installation.
** Minimum rough in opening required is to be
larger than the adjusted height of the cabinet.
*To face of door
without custom panel.
