Technical specifications
Rated voltage
Load
Detection Range
Lux Adjustment
Time Setting
Operating
Temperature
Environmental
Protection
Installation and assembly of electrical equipment must be carried
out by qualified electricians. Contact a qualified electrician in the
event of fault or break down.
www.grupotemper.com
All manuals and user guides at all-guides.com
220 - 240V~ 50 / 60Hz
Load (↓) for Lighting:
Incandescent Lamp: max. 2000W
AC Halogen Lamp : max. 1000W
LV Halogen Lamp : Max. 1000VA / 600W (traditional)
Fluorescent Lamp : Max. 900VA / 100uF
Energy Saving Lamp: Max. 600VA / 400W
LED Lamp : Max. 500VA / 400W
360º circular, max. Φ 7m at 2.5m height
Adjustable from approx.10Lux to
(learning range:10Lux - 2000Lux)
Adjustable from approx. 5sec to 30min
and Test &
-20ºC to +45ºC
IP40 (Flush mount with spring clip or European
standard junction box)
IP44 (Surface mount with junction box KDP1)
KDP1 360 FP
Presence detector
Max. 1000VA / 900W (electronic)
25x(1x18W); 12x(2x18W)
15x(1x36W); 7x(2x36W)
10x(1x58W); 5x(2x58W)
Max. 1000VA / 600W
(Uncompensated)
(include CFL & PL lamp)
"∞"and " "
Instructions manual |
