Agilent U3402A Guide De Mise En Route page 7

Annnciator
mV
µmA
µmnF
Mk
MkHz
Secondary display
µnmF
ºC
ºF
%
mV
µmA
S
Mk
MkHz
2ND
AUTO
DC
AC
DCAC
COMP
dBm
CAL
EXT
TRIG
REMOTE
LOCAL
STO
RCL
U3402A Quick Start Guide
All manuals and user guides at all-guides.com
Description
Voltage unit: mV, V
Current unit: µA, mA, A
Capacitance unit: nF, µF, mF. Not applicable for the U3402A.
Resistance unit: , k , M
Frequency unit: Hz, kHz, MHz
Polarity, digits, and decimal points for secondary display
Capacitance unit: nF, µF, mF. Not applicable for the U3402A.
Celcius temperature unit. Not applicable for the U3402A.
Fahrenheit temperature unit. Not applicable for the U3402A.
Duty cycle measurement. Not applicable for the U3402A.
Voltage unit: mV, V
Current unit: µA, mA, A
Shift mode
Resistance unit: , k , M
Frequency unit: Hz, kHz, MHz
Secondary display is enabled
Autoranging
Direct current
Alternating current
AC + DC
Compare operation
Decibel unit relative to 1 mW
Calibration mode. Not applicable for the U3402A.
External. Not applicable for the U3402A.
Trigger mode. Not applicable for the U3402A.
Remote interface control. For calibration use only.
Local mode
Store instrument state. Not applicable for the U3402A.
Recall stored instrument state. Not applicable for the U3402A.
3
