4 Technical data
For details of the rated voltage, current, frequency and/or input power, please refer to the power tool's
country-specific type identification plate.
When powered by a generator or transformer, the generator or transformer's power output must be at least
twice the rated input power shown on the rating plate of the power tool. The operating voltage of the
transformer or generator must always be within +5% and -15% of the rated voltage of the power tool.
Weight
Single impact energy in accordance with EPTA procedure 05
Hammer drill bits, Ø
Hammer drill bits, Ø
Ø drill bits for wood
Ø drill bits for wood
Ø drill bits for metal
Ø drill bits for metal
4.1 Using extension cords
WARNING
A damaged supply cord presents a hazard! Do not touch the supply cord or extension cord if damaged
while working. Disconnect the supply cord plug from the power outlet.
▶ Check the appliance's supply cord at regular intervals and have it replaced by a qualified specialist if
found to be damaged.
• Use only extension cords of a type approved for the application and with conductors of adequate gauge
(cross section). The power tool may otherwise suffer a drop in performance and the extension cord may
overheat.
• Check the extension cord for damage at regular intervals.
• Replace damaged extension cords.
• When working outdoors, use only extension cords that are approved and correspondingly marked for
this application.
Recommended minimum conductor cross-section and maximum power-cord length for 120V supply
voltage
Cord
Conductor cross-section
Conductor cross-section
Cord length
Cord length
5 Operation
5.1 Fitting the side handle
CAUTION
Risk of injury Loss of control over the product.
▶ Check that the side handle is fitted correctly and tightened securely. Check that the clamping band is
engaged in the groove in the product.
▶ Fit the side handle.
6 English
AWG 16
1,31 mm²
2,58 kcmil
25 m
75 ft
2
TE 70­AVR
18.3 lb
(8.3 kg)
11.5 J
1/2 in ... 2 3/16 in
12 mm ... 55 mm
13/32 in ... 1 1/4 in
10 mm ... 32 mm
0 in ... 23/32 in
0 mm ... 20 mm
AWG 14 AWG 12
2,08 mm² 3,31 mm²
4,11 kcmil 6,53 kcmil
30 m 50 m
100 ft 150 ft
2063039
*2063039*
AWG 10
5,26 mm²
10,4 kcmil
100 m
250 ft
