Door Assembly - Quadra-Fire DISCOVERY-I Manuel Du Propriétaire

IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and
Home Technologies does not sell directly to consumers. Provide model number and serial number when
requesting service parts from your dealer or distributor.
ITEM

#15 Door Assembly

15.1
15 Door Assembly
15.1 Hinge Pin, 1/2"
15.2 Rope, Door, 3/4" x 84"
15.3 Door Glass Assembly
Gasket, Glass Tape, 3/4" x 1/8"
15.4 Glass Frame Set
Screw Flat Head Phillips 8-32 x 1/2
15.5 Door Handle Assembly
Cam Latch
Door Handle
Fiber Handle
Key, Cam Latch
Nut, 2-Wy Side-Lock Jam 3
Washer, Sae, 3/8 (3 Ea)
16 Blank Frame
17
Tile Frame
18 Panel Assembly, Side Right
Additional service part numbers appear on following page.
23 Septembre 2016
R
Service Parts
DESCRIPTION
Beginning Manufacturing Date: July 2016
Ending Manufacturing Date: Active
COMMENTS
15.4
15.3
15.2
Nickel
7 Ft.
5 Ft.
Pkg of 12
Pkg of 24
Pkg of 3
7039-173D
Discovery I
DISCOVERY-I
Stocked
at Depot
PART NUMBER
15.5
SRV7039-040
430-5320
832-1680 Y
7000-013 Y
832-0460 Y
GL-FRM-21M
220-0490/12 Y
SRV7033-071 Y
430-1141
SRV7044-188 Y
SRV7060-212
430-1151
226-0100/24 Y
832-0990 Y
SRV7039-171
SRV7039-170
SRV7039-031
25
