Grass catcher
handle
Mulch kit
The mulching kit is integrated into the rear cover. When the rear cover is folded down, the mulching
kit blocks the rear discharge opening and fulfils its purpose. The grass is not collected and is further
shredded by the rotation of the blade!
Remove a bracket from position 1 and insert it in position 2. Lift the rear ejector guard and install the
frame that holds the rear ejector guard can.
Supports/wedge for lifting and holding the tailgate
Tailgate
