Important Safety Information

• CAUTION - Before driving, ensure that the hood shield is properly secured to vehicle.

• Do not use automatic "brush-style" car washes.

• Do not use cleaning solvents of any kind.

• Periodically check all components for tightness.

Contents - 1 Piece Set

Contents - 3 Piece Set

Hood shield

Tools Required

Preparation Before Painting / Installation

• A trial fit is recommended to ensure proper positioning and fit.

• Check fit of parts before painting as we will not accept the return of modified or painted parts.

• Wash and dry your vehicle to remove any debris and/or dirt from the installation area.

Installation Steps

Locate (4) circular holes on the underside of the front grill.

Remove any dust or debris,

Installation Instructions

NOTE: Actual product may vary from illustration.

Hood shield

Fender Protector x2

Car Wash Supplies

NOTE: Actual application may vary slightly from illustrations.

Bump On x4

Clean Towel

Align the predrilled holes in the hoodshield with the holes in the

Page 1 of 2

I - Sheet Number WTBF26 Rev.A

Fastener x4

Phillips screwdriver

underside of grill.

Alcohol Pad x2

Sommaire des Matières pour WeatherTech Easy-On Stone & Bug Deflector

Page 1 Installation Instructions I - Sheet Number WTBF26 Rev.A Important Safety Information • CAUTION - Before driving, ensure that the hood shield is properly secured to vehicle. • Do not use automatic “brush-style” car washes. • Do not use cleaning solvents of any kind. •...
Page 2 Installation Steps NOTE: Actual application may vary slightly from illustrations. Using a phillips screwdriver, install the fastener front grill hood shield fastener DO NOT OVERTIGHTEN Fender Protector Clean the fender protector mounting Expose 2” (5 cm) of tape liner from each end of the flanges location with an alcohol pad.
Page 3 Instructions d’installation I- Feuille numéro WTBF26 Rév.A Informations importantes concernant la sécurité • ATTENTION – Avant de conduire, s’assurer que le pare-insectes est solidement assujettie sur le véhicule. • Ne pas utiliser les stations de lavage de voitures à brosses. •...
Page 4 Étapes d’installation REMARQUE : La méthode d’application peut être légèrement différente de celle représentée par les illustrations. Installer la fixation à l’aide d’un tournevis cruciforme. Calandre avant Pare-insectes Fixation NE PAS TROP SERRER Installation de la protection d’aile Décoller 5 cm (2 po) de protection d’adhésif de chacune des extrémités de la protection d’aile.
Page 5 Instrucciones de instalación Hoja informativa N.° WTBF26 Rev. A Información importante de seguridad • PRECAUCIÓN - Antes de conducir, asegúrese de que la visera deflectora esté correctamente anclada al vehículo. • No utilice servicios automáticos de limpieza de vehículos que utilizan cepillos. •...
Page 6 Pasos de instalación NOTA: El uso real puede variar levemente de ilustraciones. Con un destornillador Phillips, coloque el sujetador. parrilla delantera cubierta para capó sujetador NO AJUSTE DEMASIADO Instalación del protector de guardabarros Exponga 2” (5 cm) de cinta protectora en cada extremo de los rebordes del protector de guardabarros.
