Current UCM2-LK Instructions D'installation

17760 Rowland St,
Rowland Heights, CA 91748
T 626.968.5666. F 626.369.2695.
www.currentlighting.com/aal
UCM2-LK UPGRADE KIT INSTALLATION INSTRUCTIONS
WARNING: Fixtures must be grounded in accordance with local codes or the National Electrical Code. Failure to do so may result
!
in serious personal injury. SEE BACK PAGE FOR ADDITONAL SAFETY WARNINGS AND CAUTIONS.
Les appareils doivent être mis à la terre conformément aux codes locaux ou au Code national de
AVERTISSEMENT:
!
l'électricité. Ne pas le faire peut entraîner des blessures graves. Reportez-vous à la page précédente pour obtenir
des avertissements et des mises en garde supplémentaires.
MAINTENANCE INSTRUCTIONS:
INSTRUCTIONS D'ENTRETIEN:
1. For opening and closing of the fixture, refer to instructions and diagrams on instructions.
2. A regularly scheduled maintenance program should be established to retain optimum light output and
reduce heat retention. Dusting with a soft, clean, dry cloth is normally sufficient for the optics.
Do not use alkaline or acid cleaners on reflector surfaces.
NOTE: All wiring must be done by a qualified electrician.
KEEP THIS SHEET FOR FUTURE REFERENCE.
Parts Required:
(1) LED Deck Assembly
(1) Driver Assembly
(4) 1/4-20 Screws with O-rings
(2) 8-32 Screws
Tool Required:
Philip Head Screwdriver
5/32 Allen Wrench
STEPS:
Turn off all power to existing fixture.
Make certain electricity is off before beginning maintenance procedures.
!
Assurez-vous que l'électricité est éteinte avant de commencer
!
les procédures d'entretien.
1
Remove (4) existing screws as shown. Discard
screws. Pull out existing LED deck.
2
Disconnect existing wire harness.
3
Page 1 of 3
(Rev 22/08/22
