FINAL ASSEMBLY

1. Align the door and reattach hinges to mounting plates until audible click is heard. Ensure all hinges are fully seated before
attempting to adjust door.
2. If desired, the slow close feature can be deactivated on one of the hinges. Swing the door closed once for the deactivation to be
complete. To reactivate, move switch back to original position.
1 2
NOTE: The door hinges have a three-way adjustment feature. These adjustments can be made using a #2 Phillips-head screwdriver.
3A. Side adjustment – Rotate front screw to increase or decrease door overlay.
3B. Height adjustment – Rotate cam screw on mounting plate to adjust door.
3C. Depth adjustment – Rotate rear spiral tech cam screw to adjust door gap.
3B 3C
Hinge Partially
Hinge Extended
Extended
3A
