INSTALLATION MANUAL
DGM4D
Smart Card Access Control 4 door controller
Event log
- Each controller records all events. This means that
with a network of 5 controllers, if an event occurs
on controller 1, controllers 2, 3, 4 and 5 record
the type of event on controller 1. Thus, when you
recover the events, you can recover them from
any controller and read head called TDG4D.
- When you enter a "New site code", your events
are erased, as are all indices of loss (Residents
and Passes).
- So the events are taken into account, the controller
or network of controllers must be re-configured.
Setting the controller time
- The time on the DGM4D controller was set in the
factory, so you can use your smart access control
controller immediately without having to configure it.
- If you remove or replace the battery, you must
do it with the controller on (Lithium battery reference:
CR2032 - To be placed with the controller on).
You must then check and/or reset the time and date
using the portable programmer PCV123D.
- The date by default is 01/01/98.
- The time by default is 00:00.
Notes :
If you remove or replace the battery, with the controller
off, the time and date are lost. You must then reset
the time and date using the portable programmer:
PCV123D (controller on).
Updating the smart card access control
DGM4D controller
- Refer to the Updating instructions for the smart
access control DGM4D
- Be particularly careful: in compliance with the smart
access control standard, the building managers
must make sure
the software is authorised to do so.
What to do if you lose the site code and/or the
password of the DGM4D controller?
1 – Remove power to the power input terminals
on the DGM4D,
2 – Remove the battery from the DGM4D controller,
3 – Wait a few seconds (the date is set back
to 01/01/98),
4 – Connect the DGM4D controller to the PCV123D terminal,
5 – Put back the battery,
6 – On the PCV123D, enter the site code "0 0 0 0"
and then the password "0 0 0 0",
7 – This message appears on the display "Wrong
site code" or "Incorrect password", followed
by an encrypted number,
8 – Send the encrypted number to CDVI Technical
Support and specify that the date was reset
to 01/01/1998.
Controller software.
that the person updating
9 – Technical Support from CDVI will send you
the site code and the password.
Important: Remember to set the time on the
DGM4D using the PCV123D
Turning the DGM4D on and verifying
the installation
- When the controller is turned on: the LED on the
DGM4D blinks very rapidly during the initialisation
phase. There must be at least one TDG4D head
connected to the controller so the controller is
initialised properly. If this is not the case, the
alarm relay is activated and deactivated 4 times
in a row and the controller stays in the initialisation
phase. The alarm relay continues to activate and
deactivate 4 times in a row as long as the DGM4D
controller does not detect at least one TDG4D head.
- When the controller is properly initialised,
meaning when it detects at least one TDG4D
head, the initialisation phase comes to an end.
The LED of the controller blinks slowly (about once
per second).
- When the DGM4D controller is turned on,
the indicator light for each TDG4D head is orange.
- Once the TDG4D head has been recognised
and properly initialised, the indicator light goes off.
Notes :
If the indicator light does not come on or if it stays
on after more than 10 seconds, there is a fault with the
TDG4D reader head. (Check the wiring again).
- When the controller is functioning and it detects
a problem with one of the programmed parameters
in the resident or pass tag, the indicator light
for the TDG4D head sends a luminous signal
corresponding to the problem detected:
Green, blinking fast
Solid green for 10 seconds
Red, blinking fast
for 10 seconds
Red, blinking slowly
for 10 seconds
* Incorrect tag parameters:
- Invalid start of validity - Invalid end of validity
- Loss index invalid - Time slot invalid
- Authorised days invalid - Authorised month invalid
- Authorised doors invalid - Anti-passback mode activated
EN
Tag reading
Door opening
Wrong site code or incorrect
parameter* in the tag
Tag not DGM4 compatible
or blank tag
