Important Safety Instructions
SAVE THESE INSTRUCTIONS
All sections of this manual contain instructions and warnings that should be followed during the installation and use of the SmartRack Enclosures
described in this manual. Read all instructions and warnings thoroughly before attempting to move, install or use the SmartRack Enclosures
described in this manual. Failure to comply will create a risk of personal injury and property damage and may affect the warranty.
• Keep the enclosure in a controlled indoor environment, away from temperature extremes, flammable liquids and gasses, conductive contaminants
and direct sunlight.
• Leave adequate space at the front and rear of the enclosure for proper ventilation. Do not block, cover or insert objects into the external ventilation
openings of the enclosure.
• The enclosure is extremely heavy. Use caution when handling the enclosure. Do not attempt to unpack, move or install it unassisted. Use a
mechanical device such as a forklift or pallet jack to move the enclosure in the shipping container.
• Do not place any object on the enclosure, especially containers of liquid, and do not attempt to stack the enclosures.
• Inspect the shipping container and the enclosure for shipping damage. Do not use the enclosure if it is damaged.
• Leave the enclosure in the shipping container until it has been moved as close to the final installation location as possible. The casters are designed
for minor position adjustments within the final installation area only. The casters are not designed for moving the enclosure over longer distances.
• Install the enclosure in a structurally sound area with a level floor that is able to bear the weight of the enclosure, all equipment that will be installed
in the enclosure and any other enclosures and/or equipment that will be installed nearby.
• Do not push the enclosure from the side panels to move it. Pushing from the side panels will cause a tipping hazard.
• When rolling the enclosure on its casters, always push it from behind, never pull it toward you.
• A rolling enclosure can cause personal injury and property damage if not properly supervised. If rolling the enclosure down a ramp is required, use
extreme caution. Do not attempt to use ramps that have a slope steeper than 1:12.
• Use caution when cutting packing materials. The enclosure could be scratched, causing damage not covered by the warranty.
• Save all packing materials for later use. Repacking and shipping the enclosure without the original packing materials may cause product damage
that will void the warranty.
• Do not re-ship the enclosure with additional equipment unless the enclosure was shipped with a special shock pallet ("SP1" and "SP2" models
only). The combined weight of the enclosure and installed equipment must not exceed the load capacity of the pallet. Tripp Lite is not responsible
for any damage that occurs during re-shipment.
• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support
equipment or to significantly affect its safety or effectiveness is not recommended. Do not use this equipment in the presence of a flammable
anesthetic mixture with air, oxygen or nitrous oxide.
Overview
SmartRack Enclosures accommodate all standard 19-inch rackmount equipment, regardless of vendor, and ship fully assembled for quick and easy
deployment. They feature adaptable heavy duty cabinets with variable mounting depths, making them ideal for servers. Integrated baying hardware
enables cost-effective, orderly and efficient expansion. The cabinets include quick release doors and side panels for convenient maintenance. Front
and rear doors and side panels are lockable.
The SR42UBEIS has a NEMA 12 (IP54) rating, and is designed to be dust-protected and drip and splash resistant. It features louvered front and rear
doors with sealing gaskets and dust filters. The doors seal tightly and may require pushing on the top or bottom of the doors to set them properly. The
rear door is equipped with 12 ventilation fans in 3 individually powered fan panels, ensuring constant airflow. An optional dust- and drip-resistant cable
access housing can be mounted on the top of the enclosure for protected rooftop cable access. The enclosure also features 4 dust- and drip-resistant
access ports located on the floor and rear door of the enclosure. Heavy-duty industrial casters allow long-term support and a 3000 lb. stationary/
rolling load rating. When bolted to the floor, the SR42UBEIS has a Zone 4 seismic rating.
