Button
Ex-changing auto mode and semi auto mode
•
Underunlockedstatus,bypressing""or""buttonfirstlyto
selectdesiredchannelforvaluesetting,thenpress""toselect
autoorsemi-automode.Ifpress""buttondirectlywithout
selectingonechannel,bothDA1andDA2canselectautoor
semi-automodesimultaneously.
•
Thefirsttimepressingthe""button,LEDwillflashquicklyfor
2sec.toindicatedetectorenteringintoAutomode.Press""
buttononemoretime,LEDwillkeepon2sec.toindicate
detectorenteringintoSemi-automode.
To reset settings on presence detector
Bypressing""buttonaimingtothedetector,all
settingsonpresencedetectorwillgobackto
potentiometers'settings.
To adjust Lux value
•
Underunlockmode,press""or""firstlytoselectdesired
channelforvaluesetting.Then,presscorrespondingbuttonto
selectedlightlevelthresholdissettopresencedetectorfor
switchingontheconnectedload.
•
UserscansetthedesiredLuxvaluethroughpressing""
button.
To read-in the actual ambient light level
•
Actualambientlightlevelcanberead-inasthresholdfor
switchingtheconnectedload,iftheprovidedLuxvaluesdonot
matchuser'srequirement.
Thestepsareasbelow:Press""buttontilldetector'sred
LEDflashingtoenterintolearningmode,learningtimeis10sec.
Thentheactualambientlightlevelisread-inconfirmedbyboth
loadandLEDturnonfor5sectoindicateRCDALIlearning
successfullyandthenturnoff.Afterwards,itreturnstoAuto
mode.
Note:Iftheambientlightlevelisoutoftherangeof10-
2000Lux,detectorwilllearnfor10sec,thenLEDflashesquickly
for5sec,andthealternativeof10Luxor2000Luxvaluewillbe
storeddependingonunder10Luxorabove2000Luxvalue.
•
""isonlyvalidforDA1setting.
