RC 855C

1. POWER

2. ALARM1/VOL-

3. ALARM2/VOL+

4. HOUR/TUNING-

5. MIN/TUNING+

6. SET/PRE/ M+

7. AM/FM/AUX IN

8. DISPLAY HI/LOW/OFF

9. SNOOZE / SLEEP

10. NOT USED

11. POWER JACK

12. AUX IN JACK

13. LED DISPLAY

14. BATTERY COMPARTMENT

CONNECTING THE RADIO

Plug the external adaptor into 5V

been interrupted and restored, the clock display will blink. Make sure to reset

both the correct time and alarm time for proper operation.

TIME SETTING

In standby mode, press and hold the set/pre/m+ (6), then the clock display

(13) will blink. Press the hour/tuning- (4) min/tuning+ (5) or to set the hour

and min of the clock display respectively to the correct time. press set /

pre/m+ (6) again when finished the setting, the time display will not blink.

DIMMER HIGH / LOW / OFF

On time display mode, press dimmer hi/low/off (8) to set high or low or

turn off the led display.

RADIO OPERATION

Press power (1) once, it will turn on the radio, press am/fm/aux (7) to select

fm band or am band or aux. Press hour/tuning- (4) or min/tuning+ (5) to

adjust your desired frequency. Press alarm 2/vol + (3) to increase the

volume, press alarm 1/vol- (3) to decrease the volume.

The default volume level is 12, maximum level is 16.

MEMORY OPERATION

The clock radio can store 20AM and 20FM presets.

On radio playing mode, select your desired band (FM/AM), press up min/

tuning+ (1) or hour /tuning-(4) to choose your desired frequency, long

press set/pre/m+ (6) to enter into preset mode, the preset number will

show and flash on the led display (13), then short press hour/tuning- (4) or

min/tuning+ (5) to select your desired memory numbers from p1 to p20.

press the set/pre/m+ (6) to confirm your memory setting.

Repeat the above steps, you can store your desired stations.

After setting is ok, press set/pre/m+ (6) to select your preset frequency

to enjoy radio broadcasting. Press power (1) to turn on or off the radio.

SELECT AUX IN

1. Use a cable with 3.5mm stereo jack socket to connect the AUX IN (12)

on the back to the headphone / audio from a source device

2. Select the AUX IN input by pressing more times the AM / FM / AUX IN

(7), the display shows AU.

ALARM FUNCTION

SETTING ALARM 1 BY BUZZER

In clock display mode, press alarm1/vol- button (2) once to select alarm

AM/FM ALARM CLOCK

jack (11). When electrical power has

by buzzer, the "buzzer al1" icon light up and alarm time display will flash.

Using hour/tuning- button (4) and min/tuning+ button (5) to set your

desired alarm hour.

SETTING ALARM 1 BY RADIO

In clock display mode, press alarm1/vol- button (2) twice to select alarm by

radio, the "radio al1" icon light up and alarm time display will flash. Using hour/

tuning- button (4) and min/tuning+ button (5) to set your desired alarm hour.

SETTING ALARM 2 BY BUZZER

In clock display mode, press alarm2/vol+ button (3) once to select alarm

by buzzer, the "al2 buzzer" icon light up and alarm time display will flash.

Using hour/tuning- button (4) and min/tuning+ button (5) to set your

deisred alarm hour.

SETTING ALARM 2 BY RADIO

In clock display mode, press alarm2/vol+ button (3) twice to select alarm by

radio, the "al2 radio" icon light up and alarm time display will flash. Using hour/

tuning- button (4) and min/tuning+ button (1) to set your desired alarm hour.

SLEEP FUNCTION

If you want to listening the radio while fall asleep. you can use sleep function

by setting the sleep time.

With the radio on, press the snooze/sleep button (9) to enter into sleep mode,

the 90 no. shows on the led display (13). It states 90-minutes of sleep time

and to be setted in sequence 90-80-70-60-50-40-30-20-10-off. Press the

snooze/sleep button (9) to choose your desired sleep time, the sleep timer

will change by 10 minutes each time you press the sleep button (9). The

unit will stop playing when the timer countdowns from the preset sleep time

to the end and then switch off by itself.

SNOOZE FUNCTION

On alarm sound mode, press power (1) to stop the alarm, the alarm will not

resume. But if you press the snooze/sleep button (9) to stop the alarm, the al

icon of the led display (13) will blink, and the alarm will resume after 9 minutes.

BATTERY BACKUP

This clock has a backup power system to ensure continuous operation during

power failure. Insert two AAA battery into battery compartment (14) and the

clock mechanism will continue to maintain the current time and alarm program.
