Parts List - Desa RLP155AT Mode D'emploi

All manuals and user guides at all-guides.com
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 11 of this manual.
PART NUMBER
KEY 35-FAC, NLP35A
NO. SPC-35, RLLP35A SPC-40
1 113832-01
2 113833-01
3 102445-01
4 102334-01
5 113852-01
6 113834-01
7 113846-01
8 113848-01
9 113847-01
10 097918-01
11 097917-01
12 113851-01
13 113849-01
14 113850-01
15 M11143-1
16 098219-25
113835-01
113858-02
113858-01
113858-04
109111-02
113853-01
113854-01
113802-03
** Not a field replaceable part.
113855-01A

PARTS LIST

DESCRIPTION
113832-01 Heater Body Kit
(Replacement kit will be unpainted)
113833-01 Control Box Assembly
102445-01 Piezo Ignitor
102334-01 Palnut Fastner
113852-01 Hex Nut, 5-28
113834-02 Valve w/ Thermocouple Assy
113846-01 Wire Assembly
113848-01 Thermal Switch Kit
113847-01 Electrode Ignitor
097918-01 Handle Clip
097917-01 Handle
113851-01 Fan
113849-01 Motor Assembly
113850-01 Fan Guard
M11143-1 Bushing, Strain Relief
098219-25 Cord, Power Supply
PARTS AVAILABLE - NOT SHOWN
113835-01 Hose/Regulator Assembly
____
Tradename Decal (35-FAC)
____
Tradename Decal (SPC-35)
____
Tradename Decal (NLP35A)
____
Tradename Decal (RLLP35A)
113853-01 Warning Decal
113854-01 Operation Decal
113802-04 Model Data Decal
www.desatech.com
QTY.
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
2
2
2
2
1
1
1
13
